1.Quality is our core!!!
2.We are a factory and have a very competitive price.
3.We promise nice quality and after-sale service.
4.For large machines,we will train the operators and maintenance technicians at local when we guide installation and commissioning, so the operators and technician can solve some basic problems after training.
and we will send engineers to handle trouble if they can solve the trouble.
For wine, health wine, gelatin, rice wine, soy sauce, vinegar, soft drinks, fruit and vegetable juice, sake, wine, syrup, honey, oral liquid, herbal extract, sodium alginate, starch and other clarification filtration of liquid products.
Filtration principle:
When filtering, the diatomite is firstly formed on the filter plate. The filtered liquid by diatomaceous precoats, the impurities are blocked; and pure liquid through the gap between the gap and the micro tubular or flake particles through the filter layer, which has the filtration function. With the increase of filtration time, the impurities in the pre coating will be more and more. Therefore, in the process of filtration, it is necessary to add a certain amount of diatomite to the filtered liquid into the filter tank to maintain the normal filtration process. In addition, if the filter needs to be added to a certain proportion of activated carbon.
|
Common types |
Filter area(M2) |
Motor power(KW) |
Filter leaf(pcs) |
Filter leaf dimension (mm) |
Outline dimension(M) |
|
DF-1 |
1 |
1.1 |
10 |
370 |
1.4*0.8*1.2 |
|
DF-2 |
2 |
1.5 |
20 |
370 |
1.4*0.8*1.4 |
|
DF-3 |
3 |
1.5 |
30 |
370 |
1.4*0.8*1.6 |
