NC400 Pressure plate Die Spotting Machine

Product Overview

Description

NC series vertical type die spotting machine draws essences of products of the same type at home and abroad, and is the main facility for design and development.  This product is mainly utilized for repair and maintenance of various plastic die, hardware casting die and thin-strip tensile forming die.  It, boasting convenient, fast and automatic operations, substitutes traditional simple fitting of knocking by copper bar, and greatly promotes efficiency and precision of fitting.

NC series vertical type die spotting machine adopts PLC control, human-machine interface operations, proportion pressure adjustment and chooses different pressures according to working requirements.



Model: NC400-3020

Max close force: 400T

Max lift force: 90T

Mould open space: 2600MM

Working table size: 3000X2000MM

Upper table bearing forc: 15T

lower table bearing force: 35T

Up/down speed: 70/80MM

Pressurizing speed: <25MM

Eject capacity: 15T

Eject stroke: 200MM

Out stroke of lower working table: 4400MM

Motor power: 30KW

Total Height of the Machin: 7850MM

Land Area of the Machine:  7480x5950MM
