Bioreactor
- Category: Reactors >>>
- Supplier: Shanghai Ritai Medicine Equipment Project Co. Ltd.
Share on (388226700):
Product Overview
Description
Product Description
Model: CELLIPOWER08 system MC/SS
Features:
Shanghai RITAI makes a new generation of microcarrier Cell Culture Bioreactors. We adopt centrifugal lifting type Agitator, which has features of low shearing force, rapid solution circulation , shorter mixing time, and ability of linear scale up. And we adopt new type of aeration tube, which has features of foam free deep aeration, oxygen Transfer Rate (Kla between 4-8) satisfy.. Moreover, we also adopt unique decanting column, which has features of Simple structure, stable and reliable, Perfusion rate higher than 5 times of the working volume/per day, a self cleaning function and of features of liquid level being automatically controlled
Application:
It suits for mammalian animal cell culture. it is also available for suspension culture , anchorage independent and anchorage dependent cell line. Continuous perfusion is applicable, it can increase cell density, improve the health pattern of cell, and greatly increase cell product.
Description:
| Model | CELLIPOWER08 SYSTEM | ||||||
| Working volume | 5L -300L | ||||||
| Filling volume | 65-80% | ||||||
| Material | Wetted parts are SS316L, and others are SS304. | ||||||
| Stainless steel part finish | inside surface is 0.28-0.4μm by mechanical polishing, ( passivation or electropolish are optional) outside surface is 0.4-0.8μm by satin finish. | ||||||
| Pressure | Working pressure inside vessel:0.2mpa Design pressure inside vessel: 0.25mpa Working pressure inside jacket:0.3mpa Design pressure inside jacket: 0.35mpa Pressure can be also designed according to client’s detail requirement. | ||||||
| Agitation | 1.Fermentor use servo motor or SEW decelerator 2.top mechanical agitator , single mechanical seal 3.speed range:50-200rpm 4.Centrifugal lifting type agitator | ||||||
| Equips of vessel | 1.using alcohol flame inoculation 2.electrical heater 3.PH,DO, temp. sensor foam and level probe port, etc. | ||||||
| construction | Floor type One fermentor vessel with one control system (simens PLC and HMI) | ||||||
| Operating panel | Chinese and English version | ||||||
| Main components and controls of system | |||||||
| PH | 1.On-line check and measure, and digitization fully automatic control; 2.PH, CO2 and base gang control. Mass flow meter automatically adjusting CO2, peristaltic pump automatically adjusting base. 3.Control range 2-12pH, measure precision±0.01 pH, control precision±0.1 pH; 4. It has auto alarm function. 5.pH sensor and signal transmission line, mettler Toledo | ||||||
| DO | 1.On-line check and measure; digital display. 2.Range 0-200%, precision ±1%; 3. It has auto alarm function; 4. DO sensor and signal transmission line, mettler Toledo | ||||||
| Feed controlperfusion | 1.Automatically control and automatically alarm; 2.peristaltic pump automatically feeding and perfusion | ||||||
| Temp. control | 1.PID fully digitization signal processing, digitization control settings 2.Measure range 0-150°C, control range 15-45°C,control precision±0.2°C 3.Pt 100Ωtemp. Sensor 4.system with electrical heater to control the temp inside vessel | ||||||
| Rotate speed | 1.Automatically control , with auto alarm function 2.servo or simens frequency converter to adjust the speed. | ||||||
| Air flow | Automatically adjusting with massflow meter | ||||||
| Pressure | Automatically adjusting with pressure transmitter and pneumatic valves | ||||||
| sterilization | 1.it can be SIP by connecting with steam 2.Automaticall control with pneumatic valves (optional) | ||||||
| Control | Siemens PLC, and Siemens 10.4” LCD touch screen(HMI) and RITAI program | ||||||
| PC | 1.PC with kingview software for recording function (optional) 2.PC with simens remote control and kingview recording function (optional) 3.printer (optional) | ||||||
Packaging & Shipping
Packaging: wooden case
Shipping: by sea or by air
Our Services
We offer design, customization, installation, maintenance services, etc.
Company Information
Shanghai Ritai Medicine Equipment Project Co., Ltd. mainly specializes in innovation and development of sanitary stainless steel pressure vessels, atmospheric pressure vessels, fermenters, valves and piping system which are widely used in the following fields, such as pharmacy, biology, chemistry, food and drinks industry, etc.
It is qualified to design and manufacture pressure vessels under the authorization of ASME, EU PED/CE, and ISO 9001:2008.
