Мягкое пусковое устройство двигателя 600 кВт

Three ways to control the soft starter

Keyboard Control (Local)

Start and stop terminal input control

Programmable input terminal control

Noise

Under normal work conditions, the noise of the running device is less than 80db (A class)

Vibration

The vibration acceleration of the installation site is not more than1.5g

Pollution Level

3

Storage temperature

-25°C~+70°C

Working temperature

-25°C~+50°C

Relative Humidity

Maximum 80% (when temperature is 20°C), no condensing, flammable, explosive and corrosive gases

Altitude

Installation site altitude is not more than 1,500 meters (when altitude is more than 1500 meters, please inform us when make order)

Cooling

Forced air cooling

Applicable standards

GB14048.6_1998(IEC947-4-2)

Rated insulation voltage

660V

Rated voltage

380V or 660V

Voltage fluctuation range

±10%

Controlling power supply voltage

220V

Controlling power supply frequency

50Hz

Control power supply voltage fluctuation range

±20%

Control power supply frequency fluctuation range

±1%

Working phase

3 phase

Programmable input

DC24V,built-in power supply

Output relay

250VAC, 6A

Start interval time

Starting interval time is more than 5 minutes, the starting time is not more than 5 per hour

Start function

Slope Start

Limit start

Kick start

Slope steady start

Steady start

Point start

Stop functions

Freely stop

Protection function

High voltage

Low voltage

Input missing phase

Output missing phase

Imbalance current

Start over current

Run over current

Run inverse time overload (inverse time 1, 2, 3, 4)
