Lightning protection box 220V voltage limiter surge suppressor box
- Category: Other Electrical Equipment >>>
- Supplier: Zhejiang THOR Electric Co. Ltd.
Share on (504205663):
Product Overview
Description
Product Effects
Product Overviews
The lightning protection box is a kind of lightning protection equipment. It is mainly installed in power distribution rooms, distribution cabinets, AC distribution panels, switch boxes, and other important equipment that are vulnerable to lightning strikes. Damage due to lightning overvoltage ingress along power lines.
Main technical parameters
| Main technical parameters | TRSX | ||||
| Max continuous operating voltage Uc(VAC) | 385V | ||||
| Rated operating voltage Un(VAC) | 220V | ||||
| Voltage protection level Up(kV)≤ | 1.5KV | ||||
| Max discharge current (8/20μS) lmax(kA) | 20 | 40 | 60 | 80 | 100 |
| Nominal discharge current (8/20μS) ln(kA) | 10 | 20 | 30 | 40 | 60 |
| Remarks | Other Uc can be customized | ||||
| SPD according to IEC61643-1/EN61643-1 | type2/ ClassⅡ | ||||
