EDON DC inverter plasma cutter CUT-40 IGBT CUTTING MACHINE
US $65.00-$91.00
High Quality NBC 270F DC Inverter MIG Welding Machine
- Category: Plasma Welders >>>
- Supplier: Zhejiang Dongsen Electric Appliances Co. Ltd.
Share on (584682188):
Product Overview
Description
Great Quality MIG-270FI DC Inverter IGBT MIG Welding Machine
Features:
1. Superior performance:
3ph/AC320-460V.Rugged construction combines with the unique designed rectifier to deliver extreme durability in rough environments,and significantly reducing noise during operating.
2.Excellent weld properties: unique circuitry delivers a better weld,reduces spatter and fumes,make it perfectly suits all positon welding.The spot MAG process provides high welding speed,good looking appearance and free of burn-penetration,makes it especially suitable for the furniture industry.
3.The compact cylinder holder makes it very convenient for movable position jobs.
4.Adaptive features of continuous welding,spot welding,automatic spot welding,crater helps to meet the different welding requirements easily.
5.Great advantages of high welding speed,less defect and deformation,less after-treatment,lower running costs,etc
Applications:
Widely used on the high efficiency semi-automatic welding of various material such as aluminum and alloy,carbon steel,stainless steel,copper alloy,etc
Specifications:
| Model | Unit | NBC-270F | NBC-315F | NBC-350F | |
| Minimum order quantity | PCS | 30 | |||
| Input voltage | V | 220/380±15%(3 phases) | |||
| Rated input power | KVA | 11.6 | 14.7 | 17.3 | |
| Rated input current | A | 17.6 | 22.4 | 26.3 | |
| Current adjusting range MIG | A | 50-270 | 50-315 | 50-350 | |
| Voltage adjusting range MIG | V | 26.5 | 29.8 | 31.5 | |
| No load voltage | V | 18-33 | 18-40 | 18-45 | |
| Feed speed adjusting range | m/min | 3.0-16 | 3.0-16 | 3.0-16 | |
| Wire diameter applicable | mm | 0.8-1.2 | 0.8-1.2 | 0.8-1.2 | |
| Rated duty cycle@40°C | % | 60 | 60 | 60 | |
| Efficiency | % | 85 | 85 | 85 | |
| Power factor | 0.7 | 0.7 | 0.7 | ||
| Protection class | IP21 | IP21 | IP21 | ||
| Insulation class | F | F | F | ||
| Machine size | CM | 72x38x63 | 72x38x63 | 72x38x63 | |
| Wire feeder size | CM | 70x33x45 | 70x33x45 | 70x33x45 | |
| Weight | KGS | 74 | 87 | 96 | |
Welcome to visit our company and establishing business relations with us.
Contact
Jane Wei
Tel : +86-0579-89086167
Fax : +86-0579-87799367
Mob : +86-18545957934
Whatsapp:+86-18545957943
If anything I can help , just feel free to contact with me
