Compound Base/ Composite Mat for waterproof membrane

Product Overview

Description

Description

Compound base is mainly used as substrates for waterproof bitumen membrane production. It is characterized by excellent dimensional stability, high tensile strength, and cheapness compared with polyester mat as such other carrier.



• an ideal substrate material for asphalt roofing felts.
• act as the lining for roof insulation layers to protect polymer foam insulation from the damaging effect caused by chemical solvents in bitumen so as to prolong the lifetime of heat insulation layer.



 Technical Data

Item	Area Weight	Mesh size	Tensile Strength		Shrinkage (230°C)
			MD	CMD
Unit	G/M2		N/5cm	N/5cm	%
Specification	90	4x4	≥350	≥200	-
	100	5x5	≥400	≥250	-
	110	5x5	≥500	≥450	-
	120-A	6x6	≥550	≥350	-
	120-B	6X6	≥550	≥500	-
	130	7x7	≥600	≥500	-
	*140-S	5x5	≥700	≥600	-

Remark: *140-S is an improved product with higher dimensional stability and strength.



Loading Quantity

Area Weight	Roll Width	Roll Length	Quantity for 1x40'HQ (117rolls)
G/M2	M	M	M2
90	1.0	1400	163800
100	1.0	1300	152100
110	1.0	1250	146250
120-A	1.0	1200	140400
120-B	1.0	1200	140400
130	1.0	1150	134550
140	1.0	1000	117000



Remark: The export package for compound base is small roll size, in which way we can load more in one container and lower the unit sea freight for each square meter. But if you want big roll size, we can also produce.
