step motor for 3d printer accessories (60004593553)

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description


 Manufacturers of Permanent magnet(PM) Stepper Motor & PM Synchronous Motor:





1. PM Stepper Motor:



Diameter8mm10mm15mm20mm25mm35mm42mm55mm
Model No.PM8S-020PM10S-020PM15S-020PM20S(L)-020PM25S(L)-048(024)PM35S(L)-048(024)PM42S(L)-048PM55L-048





2. PM Stepper Motor with gearbox(with different gear ratio):



Diameter10mm15mm20mm24mm25mm28mm35mm42mm
Model No.PG10S-020PG15S-02020BYJ4624BYJ48PG25S-04828BYJ4835BYJ46; PG35L-048PG42L-048





3. PM Linear stepper motor(with lead screw):



Diameter8mm10mm25mm
Model No.PL8S-020PL10S-020PL25S-048(024)





Application :

HVAC/R Valve Actuation

Office Automation Printers, Copiers, Data storage

Medical Applications Pill dispensing Analysers

Telecommunication Antennae positioning Switching lines

Other Industries & Applications Robotics



Highlights :

Excellent open loop control - No encoders necessary

Digitally controlled - Easy to use with a micro processor

Cost effective - compact design, lower integration cost

Maintenance free - motor is brushless

Winding possibilities – Bipolar



General Specification:



ItemSpecification
Step Angle Accuracy±8%(full   step, no load)
Resistance Tolerance±10%
Inductance Tolerance±20%
Temperature Rise80.C Max.(rated current,2   phase on)
Ambient Temperature-20.C~+50.C
Insulation   Resistance100MΩMin.   ,500VDC
Dielectric Strength600VAC   , 1s , 3mA





Specification:



ModelStep Angle
(Deg.)
No. of
    Phase
Rated   Voltage
(VDC)
Resistance
    /Phase(Ω)
Holding Torque  (gf.cm)Max Pull-in Rate(PPS)Figure
PM35S-048-2487.525203003201
PM35L-048-2377.5412604505002
PM35L-048-2627.545104003503
PM35L-024-2511545161802004
PM35L-0487.5412305504005
PM35L-024-2461522412 5006







Dimension:




Customization On Call

Coil Modifications - Resistance and Inductance.

Magnets - to yield higher linear force or reduced detent levels.

Higher Strength Plastics for higher impact forces.

Reduced or increased Detent Force to suit the application.

Screw - metric or imperial tips, length.

Special Flanges, Connectors, End of motion detection sensors.

Wire Harness - connectors, pins, lead length, shrink tubing.
