High Quality Flexographic Printing Plate, 1.7mm Thickness Resin Flexo Polymer Plate, China Photopolymer Flexo Plate

Product Overview

Description

Packing & Delivery

Packing details: Standard export carton or as requirements

Delivery details: About 20 workdays after final confirmation



1. Item

High Quality Flexographic Printing Plate, 1.7mm Thickness Resin Flexo Polymer Plate, China Photopolymer Flexo Plate



2.Description

1)Excellent dot and isolated line reproduction

2)Solid printing performance

3)High latitude of exposure and processing

4)Good ink transfer

5)High impression



3.Process Parameters

Type		R-228	R-170L	R-170H	R-114
Thickness(mm)		2.28mm	1.70mm	1.70mm	1.14mm
Back exposure(seconds)		18-25	15-21	35-60	35-60
Main exposure(seconds)		8-20	7-13	7-20	10-16
Rinsing(minutes)		5-7	5-7	5-7	5-7
Minimum drying time(hours)		1.5-2	1.5-2	1.5-2	1.5-2
Detackfying(minutes)		8-15	8-15	5-7	8-15
Post exposure(minutes)		5	5	5	5

1) Platemaking conditions:   modulator tube 80W(intensity in 365nm:9.7mW/cm2),Temperature of plate maker:24-30°C

2) All the parameters recommended above are all based on our platemaker,clients should adjust the data according to your own platermaker,power of ultraviolet lamp,depth of the files and other demands for the printing.Clients need to test on your machine.



4.Usage Scope



5.Packing



6.Processing



Any concerns, please feel free to contact me!
