Product Overview
Description
Product Description
Features:
- steel cable available
- ideal for use with conventional drill rigs
- strong lifting power up to 3 tones
- easy to operat
- safe to use
- reliable performance
Wireline winch is an important lifting tool for conventional drill rig. JINSHI wireline winch is widely used in deep mining and exploration drilling.
Core drilling winch with electrical motor or diesel engine, suitable for diamond core drilling of depth capacity:
500m,1,000m,1,500m, 2,000m, the details specifitcation is as below:
| WIRELINE WINCH | JS600 | JS1000 | JS1500 | JS2000 |
| HOLE DIAMETER | D46-75 | D46-75 | D46-75 | D46-75 |
| DEPTH | 600 | 1000 | 1500 | 2000 |
| ROLLER DIAMETER | 130 | 168 | 168 | 168 |
| ROLLER MAX DIAMETER | 400 | 450 | 550 | |
| ROLLER LENGTH | 280 | 330 | 405 | 550 |
| STANILESS STEEL DIAMETER | 5.2 | 5.2 | 5.2 | 6.1 |
| STAINLESS STEEL LENGTH | 720 | 1248 | 1632 | 2150 |
| MAX. LOAD CAPACITY | 530 | 990 | 1120 | 1400 |
| MAX. LOAD CAPACITY | 203 | 417 | 503 | 750 |
| ELECTRIC MOTOR | YD132M-8/4 | Y132S-4 | Y132M-4 | Y13M-6 |
| VOLTAGE | 3/4.5 | 5.5 | 7.5 | 7.5 |
| SPEED | 720/1440 | 1440 | 1440 | 1000 |
| SIZE | 720*680*830 | 900*726*860 | 900*726*860 | 1500*750*900 |
| WEIGHT | 220 | 420 | 485 | 600 |
Company Information
Packaging & Shipping
standard export package---plywood case or iron case
Our Services
Jinshi will response in 8 hours to the problems caused by our products. When necessity arises inside the country, technical support will arrive in 24 hours within a 1000 kilometers radius of the company, will arrive in 48 hours for other parts of China. Due to the limitation of branch offices in foreign countries, technical support will arrive your work site in 15 days after visa is issued.
