Our factory specializes in manufacturing lumber machinery. Our main products are veneer lathes and hotpresses. Our factory is one of the provincial high-technique enterprises, the provincial "Contract-Keeping and Promises stressing Enterprises", the provincial "Consumer Satisfying Unit" and one of "Lin Yi Top 100 Powerful Enterprises". We have 20 national patents and our products have attained CE certification. Our factory has passed the evaluation of ISO9001 quality certification. Our products sell well in 26 provinces and cities in our country and are also exported to the European Union, the Philippines, Vietnam, Russia, Malaysia, Thailand, Kazakhstan, India, Indonesia, Iran, Pakistan, Turkey and Mexico. Please feel free to contact us for further information. rubber hydraulic heat hot press machine
Product Description
Type
BY21-4x8/20-1
Structure
Composition Frame
Working Pressure
2000Tones
Hot Platen Size (L*W*T)
2750*1370*60mm2750*1370*80mm
Layer No.
1Layer
Separation between Layers
500 mm
Cylinder No.& Diameter
6units Φ400 mm Cylinders
Cylinder Stroke
500mm
No-load Closing Time
16s
Hydraulic System
Microcomputer manually /Automatic controlled
Control System
Main pump:2pcs Shanghai Aviation 250
pump(made by Japanese Technic)
Main motor: 11kw
Pressurized pump: 7.5kw
Pressurized pump: 10ml/rev plunger pump
Heating System
Hot Oil
Upper&Bottom Crossbeams Thickness
1000mm,1100mm200mm
Plate Main Frame Thickness
40,22 mm
Weight
39 tons
Our Services
hot press machine Advantages:
1.The use of aircraft alloy tank side note,
2.Domestic of the art hydraulic system
3.PLC programmable control system so that it smooth,rapid closure,stable,effective and pre loading
4.Hot platen rubber hydraulic heat hot press machine :
It is drilled from excellent carbon solid steel and it is high precision, high strength and durable.
It is manufactured on special worktable,so as to keep the hot platen easy to operate.
5.Heating system rubber hydraulic heat hot press machine :
It can be heated by steam boiler,oil heater or electric oil heater.
The steam boiler is low in cost and suitable for common production,yet it is high pressure vessels,
so it should be operated carefully.
As to the oil heater,it is adjustable,safe, uniform temperature,energy saving and so on,
yet it may cost much than steam boiler.
The electric oil heater is environmental protection instead of using coal or wood as it’s fuel,
but it may cost lots of electric energy.
6.Hydraulic system rubber hydraulic heat hot press machine :
It is “Triple Filter”and it has excellent oil pump and electric motor.It uses right-angled one-way valve so that it can work smoothly.The pressure is adjustable.
7.Cylinder rubber hydraulic heat hot press machine :
It is worked through excellent CNC precision machine tool.It uses high quality oil envelop so as to avoid of oil leaking.
8.Control system rubber hydraulic heat hot press machine :
Microcomputer ,Manually/Automatic controlled.
It can lift the hot platen,close the separation,add the pressure,keep the pressure,keep time, descend the hot platen and so on.
