Innovative Design Fabrication and Engineering - Bolted Facade System
Point Supported Glass Curtain Wall is also called Point Fixing Curtain Wall or Bolted Glazing System, is one type of non-frame curtain wall that consists of glass panels, point-fixing components on such panels and their supporting structures. Adopt tensioned cable / rod system as supporting structure of the point-fixing glass curtain wall. The entire structural system is made of cable / rod, stainless steel rod, glass connecting claw and so on. According to the actual situation of the main structure, horizontal and vertical direction could be selected as the main forced direction, tensioned cable / rod on the main forced direction as the bidirectional forced system and could adopt two kinds of form, fish-bellied or cross type. According to various elements of the system, it could be divided into tensioned cable system, tensioned cable / rod hybrid system and so on, and could be flexible composite applications. tensioned cable / rod system as space tensioned structural support system, the main technical characteristics are as follows.
-Transparent sense of the whole curtain wal l is rather strong, and the supporting system is simple and generous.
-The special metallic texture of stainless steel cables, rods and other elements highlights the unique structural aesthetic feeling with a strong decorative effect;
-System technology and manufacturing processes are well-developed and reliable, so the accuracy and quality etc are easily to be guaranteed;
-Systems are constituted relatively simple and reasonable, economical and practical;
-Space tensioned structural system needs certain embed dimension, taking up some interior space;
-In the structural system, all the pre-tension forces are imposed on the main structure at the boundary of curtail wall, and thus a corresponding increase in the bearing capacity of the main structure is required.
Qingdao AEON Engineering Co., Ltd is a professional leader in design, manufacture and install architectural envelopes, including aluminium glass curtain walls, windows and bolted glazing systems ., etc for domestic and international markets. Here at AEON we have full commitment from concept through to completion delivering the project on time and budget. AEON developed to provide a specialist service in the design, manufacture and installation of glazed structures comprising glass facades, rooflights, canopies, bridges, balustrades and bespoke projects. Our designs are produced using tried and proven details developed by our own in-house engineers. Attention to detail and pride in our work enable AEON to offer a service which is second to none.
We will work with you to find the right system to meet your design's aesthetics and performance.
Factory Show
Design & Install
Products List:
• Aluminium glass curtain walls
• Bolted glazing systems
• Glass windows and doors
• Glass rooflights and canopies
• Glass Balustrades etc
• High Performance Glass Solutions for Day lighting and Energy Efficiency
• Metal Panel Integrations with complex curtain wall applications
Glass Curtain Wall System:
• Frame Supported Glass Curtain Wall
• Unitized Glass Curtain Wall
• Point Supported and Cable Tension Curtain Wall
• Full Glass Curtain Wall
• Double Skin Glass Curtain Wall
• Photovoltaic Curtain Wall
Frame Supported Glass Curtain Wall lists.
• Exposed Frame Curtain Wall
• Hidden Frame Curtain Wall
• Semi-hidden Frame Curtain Wall
• All Glass Curtain Wall
Project Show
It was realized at a very early stage that the control of manufacture should be in-house in order to ensure that all components are produced within acceptable tolerances. Our experience and the decision to offer a unique service to architects and contractors has met with long-term success and our abilities and specialist expertise have helped to solve the problems associated with composite steelwork and glazing structures where fabrication to very fine tolerances is critical for the acceptance of the Glass Curtain Wall and the appearance of the finished projects. We have trained specialist site teams, supervised by project managers, who are skilled in the installation of all components included in the contract.
