BEIBEN Water Tanker Truck 15000 Liters / 15 m3 Water Trucks

Product Overview

Description

1. Parameter of Beiben  6*4  water tank truck

North Benz BEIBEN Water Tanker Truck 15000 Liters / 15 m3 Water Trucks
Brand:	North Benz
Driving type:	RHD / LHD
Cabin:	NG80B , One Sleeper
Engine brand:	Weichai
Engine model:	WD615.56 EURII
Engine type:	Diesel 4-stroke direct injection engine, 6-cylinder in-line ,with water cooling, turbo-charging & intercooling
Displacement:	9.726 liters
Max. output:	270hp@2200rpm
Max torque:	1100NM@1300-1600rpm
Bore/Stroke(mm):	126/130
Specific fuel consumption:	198g /Kwh
Gear box:	Fuller 9 speeds  (9JS135B)
Clutch:	GF430 spring type
Steering:	ZF8098
Front axle:	Benz front axle
Rear axle:	Benz driving axle (punching-welding axle housing, double Reduction driving axle, inter-wheel differential and differential lock)
Tyre :	12.00R20 (rim: 8.0-20)
Max. speed (km/h):	85
Kerb. mass:	11300 kg
Total mass:	25000kg
Fuel tank(L):	300L
Wheel base (mm):	4800
Front overhang (mm):	1410
Rear overhang (mm):	2666
Front track (mm):	1995
Rear track (mm):	1800
Approach angle:	26degree
Departure angle:	22 degree
Dimension (mm):	10576X2500X3225
II. TANK
Capacity of tank:	15m3(including Pump)
Material:	Q235B Normal black Steel metal sheets of in down of in down 5mm and side 4mm thickness







2. Company introduction

HUBEI VELDLION MACHINERY CO., LTD is a special purpose vehicle manufacturer that has the capacity of self-research and development,production,export and before and after sales service.



1. At present Our Truck with Euro 2 and Euro 3 Euro 4  Emission Standard;

    Drive model:4*2,6*4,8*4 ,6*6,4*4, 10*8 ;



   Chassis Brand : Dongfeng, FAW, Auman, Shacman, Sinotruck, etc.

2. Cab: Flat-head with one sleeper(optional), comfortable design, rated passengers:3, with air condition;

Steering control: Left hand drive /Right hand drive optional;

3. Engine model: Dongfeng Chaochai(95HP-120HP),Yuchai(140HP-240HP),(140HP-260HP),Weichai(266HP-336HP).

4. Loading weight(tank capacity): 5T(CBM), 8T(CBM), 10T(CBM), 12T(CBM), 15T(CBM), 20T(CBM), 25T(CBM), 30T(CBM).]

5. Front/Side/Rear sprinkler, equip with High-Power water cannon (360° rotatable), adjust water to high or low(spray like columnar,vaporific,drizzle).

 6. Adopt of chinese famous brand“zhejiang weilong” dedicated water cannon( introduction of Italy technology), advanced and reasonable design, fast and easy to use. Moreover, the cannon with high-pressure, long suction head and long serving life feature. The sale volume is always top for a decade in china domestic market, with 93% market share.
