sulfide forming mold temperature controller

Product Overview

Description

 sulfide forming mold temperature controller

  standard water mould temperature controller

1.PID temperature control – regulates error within + 0.1℃,continuously and constantly, with high efficiency and energy saving.

2.Six series of protective measures – boot automatically exhaust & shut down automatically cooling protection, thermostatic and circuit alarm, phase fault protection, pump protection, overheat protection, oil shortage protection.

3.LCD shows the actual and set temperatures – direct and visual operations.

4.Visual and easy operations, easy to maintain.

5.Stainless steel tank – durable without leakage or rust.

6.Circumfluence design enables recollection of diathermanous oil, easily and rapidly.

7.Exquisite appearance with delicate size

Model	XC- TM9KW-W	XC-TM12KW-W	XC-TM18KW-W	XC-TM24KW-W	XC- TM36KW-W	XC- TM60KW-W
heat transfer medium	water
highest temperature	1000C
Pump power(kw)	0.37	0.75	1.5	1.5	2.2	3.75
Pump flow(L/min)	42	56	160	160	315	380
Throw of pump	28	38	27	27	26	35
Heating power	9	12	9*2	12*2	12*3	60
Inlet of medium	3/8'(6mm)*4	3/8'(6mm)*4	1'*1	1'*1	1.5"*1	1.5"*1
Dimension(mm)	739*310*643	739*310*643	990*520*983	990*520*983	1090*520*983	1380*530*1083
Net weight(kg)	46	50	65	100	110	135
