item | value |
Certification | Reach |
Customized support | OBM |
Place of Origin | China |
Guangdong | |
Brand Name | SKOOCOM |
Model Number | SC0526GC |
Application | General |
Temperature of Media | Medium Temperature |
Power | Solenoid |
Media | Gas |
Port Size | 3.0mm |
Structure | Diaphragm |
Rated voltage | DC4.0V/DC6.0V/DC12.0V |
Rated current | 528mA/380mA/185mA |
Resistance | 7Ω±10%/15.5Ω±10%/65Ω±10% |
Exhaust Time | Max. 3.0 seconds from -300mmHg reduce to- 15 mmHg at 100CC tank. |
Leakage | Max. 3mmHg/min from -300mmHg at 100CC tank. |
Insulation Level | A |
Apply for | Air |
Life test | 200,000 Times |
Environment | 0~50 ℃,75% RH |
