Price:$32,810.00 - $33,825.00

Quantity:


Product Overview

Description


























The  cold press which has a large daylight. A pack of spread veneers, ususally enough for two or three hot press loads, is placed under pressure at normal atmospheric conditions.The aims are to transfer glue from the spread to the unspread surface of the veneer to obtian a better glue bond and to develop some strength in individual panels.


The main specification of  cold press :

































































ModelBY814 x 8/4CBY814 x 8/5B
Nominal pressure(KN)40005000
Unit pressureof board surface(Mpa)1.31.3
Width of press board (mm)2700 x 13702700 x 1370
Max. working stroke (mm)10001000
Net opening (mm)300-1300300-1300
Diameter and quantity of pressure cylinders (mm)Φ 320/ 2 piecesΦ 360/ 2 pieces
Diameter and quntity of lifting cylinders (mm)Φ 80/ 2 piecesΦ 80/ 2 pieces
Feeding speed (m/min)6.786.78
Total motor power (kw)16.116.1
Overall dimensions (mm)3500×2400×46503500×2400X4750
Weight (kg)1800018000
