copper wire plating machine

Product Overview

Description

copper wire plating machine



Usage for LY-3000A/5000A/8000A Electroplating Machine:

LY-3000A/5000A/8000A Electroplating Machine can make copper electroplating steel(CCS) wire,copper electroplating brass(Cu-Cu) wire and copper electroplating aluminium(CCA) wire.



Technical Parameter for LY-3000A/5000A/8000A Electroplating Machine :

Machine Type	3000A	5000A	8000A
Control System	Button
Main Power Control	Controlled by Electric Motor
Take-up Power Control	Controlled by Torque Motor
Diameter of Wire (mm)	Ø1.00-Ø1.20	Ø1.20-Ø1.60	Ø1.60-Ø3.00
Main Motor (KW)	4	5.5/7.5	7.5/11
Take-up Motor	YLJ132-16	YLJ132-40	YLJ132-40
Take-up Method	Shaft/ Axis
Traversing	Palm Shaft
Transmission	Tri-Angle Belt Chain
Speed (m/min)	0-100	0-100	0-100
Rectifier (A)	3000	5000	8000
Dimension (L×W×H)(mm)	18000×1200×1400	22000×1600×1600	23000×1800×1600
Weight (KG)	4000	5000	65000
Quantity of Wire	Sing Head or Multi Heads











After-Sale Service:

1. In order to help customers are able to operate the machine correctly, trainings on operation, maintenance and simple repair can be supplied if necessary.

2. Mechanical parts are provided one-year limited warranty, and electrical parts are six-month since the shipment date.
