800 2170/2400 2500 МГц двухдиапазонный радиочастотный пассивный комбайнер или диплексер полости

Share on (60332488818):


Price:45,00 $

Quantity:


Product Overview

Description



Product Description


 800-2170/2400-2500Mhz Cavity Diplexer


 Technical Specifications:































































Product Number



XL-ML2-IN3HA



Channel



Port 1



Port 2



Working frequency



800-2170



2400-2500



Insertion loss(dB)



≤0.5



Ripple(dB)



≤0.4



Rejection



≥80dB



VSWR



≤1.25



Input impedance



50



Input power



≥200



Third-order intermodulation



≤-145dBc@43dBm×2



working temperature()



-20~+55



Port Type



N(female)



Dimensions(mm)



171mm*107mm*21mm
















Packaging & Shipping


1.Packaging:paper box;


2.Delivery time:usually within 3-14 days after payment;


3.Shipping ways:DHL/UPS/FEDEX/EMS etc;


4.Payment ways:T/T,Western Union,Paypal,Alibaba Trade Assurance.





Our Services


1.Your inquiry related to our products or prices will be replied in 24 hours;


2.Well-trained and experienced staffs to answer all your inquiries in fluent English;


3.Monthly output over 2000pcs;


4.Strong package;


5. Sample order in small quantity is acceptable;
