HW383 Spandex Yarn Covering Machine
Product Description
Product Description:
HW-383 covering machine is applicable for producing single covering yarn and double covering yarn which yarn number is less than 150 dex. The applicable material includes lycra, polyester, silk & nylon. This machine is economical because it has a condense structure and it will not occupy much area.
Main Features:
1. Good mechanical forming, easy operation
2. Star delta starting. The machine runs stably with less broken yarn, average twist and excellent quality.
3. There are three groups of gear transformation for twist, drafting and winding. They can be adjusted easily to meet different requirements.
4. Multi-function for yarn covering and twisting which is suitable for special yarns, threads and silk
HW383 Specification
HW383 Main Specifications
1 | Type | Two sides and two layers |
2 | Mechanical spindle speed | 8000r/min-14000r/min |
3 | Spindle number | Single covering yarns 192 |
Double covering yarns 96 | ||
4 | Tension times of core | 1.6-4.5 |
5 | Range of covering twist number | 200-3500T/M |
6 | Spindle gauge | 260mm |
7 | Total power | 15Kw |
8 | Start mode | Y-Δ slow starting |
9 | Covering yarn tex | 70-600D |
10 | Capacity of covering fiber | 750g -950g |
11 | Size of bobbin | 140 x Φ 76 x Φ 36 |
140 x Φ 84 x Φ 36 | ||
150 x Φ 90 x Φ 40 | ||
135 x Φ 90 x Φ 40 | ||
12 | Capacity of take-up | 1500g -1600g |
13 | Size of receiving core | 220 x Φ 75 x Φ 64 |
200 x Φ 75 x Φ 64 | ||
14 | Winding speed | Max. 40m/min |
15 | Twist direction | S or Z |
16 | Dimensions (mm) | 16400 x 1462 x2050 (L x W x H) |
Customer Visiting
Customer Visiting:
Packaging & Shipping
Packaging & Shipping:
We mostly use the nude cargo with waterproof plastic bags. We will separate the whole machine into sections after adjustment, and then put each section one by one into the container.
FAQ
FAQ:
Are you the manufacturer or the trading company?
We are the experienced manufacturer of textile machines, especially for the two-for-one twisting machines, doubling winder machines, yarn covering machines and etc. We have got the self-support imports and exports right.
What is your advantage compared with other textile manufacturers?
We are expert at making yarn machines for almost 20 years and we have a professional technical team who can provide special customer requirements. Our machines have been exported to a lot of countries such as Vietnam, South Korea, Uzbekistan, the Philippines, Tunisia, Morocco, Iran and so on.
What kind of service can you offer?
Design with your requirements by professional team.
ISO 9001:2008 certificates and letters patent.
Engineers go overseas for training.
How to check my order at last?
We warmly welcome you to visit our company in Wuxi, which is close to Shanghai, for checking your machines. If you don’t come here, we can also take photos and videos for your confirmation.
