Max 5000RPM high speed slip ring with bore size 12.7mm 12 circuits 2A
Max 5000RPM high speed slip ring with bore size 12.7mm 12 circuits 2A
Max 5000RPM high speed slip ring with bore size 12.7mm 12 circuits 2A

Max 5000RPM high speed slip ring with bore size 12.7mm 12 circuits 2A

Share on (60342803393):


Price:

Quantity:


Product Overview

Description








High speed slip ring with max 5000RPM


hole size 12.7mm,


12 circuits signal 2A


work speed 5000RPM




















drawing













specification







































































Technical Data
Circuits No12 circuitsCurrent5A
Voltage<250 VDC/VACMax speed5000RPM
Through hole size12.7mm(or <=12.7mm)OD56mm
Housing materialStainless steelTorque0.1N.m;+0.03N.m/6 circuits
Electrical Noise<10mΩ @6VDC,50mA,5RPMContact Resistance<20mΩ(AWG16#,300mm)
Dielectric Strength800VDC@50Hz,10sLead wire SpecUL Teflon@Awg22,Awg16
Insulation Resistance1000MΩ@600VDC,10sLead wire length300mm
Work Temperature-40°C to 150°CIP gradeIP54
Mechanical vibrationMIL-SID-810EWork Humidity10% to 85% RH
MaterialRoHS compliantContact materialPrecious metal:gold-gold
