17m Spider wheel concrete placing boom

Speciifcatioon

HGY-13

HGY-15

HGY-17

Placing radius

13m

15000mm

17m

Engine Power

4kW

4kW

5.5KW

System pressure

20Mpa

20MPa

20Mpa

Elevation angle

-2~84.4°

0°~90

-4°~90°

Rotation

360°

360°

360°

Rotation Speed

0.46r/min

0.2~0.3r/min

2500 kg

Pipeline diameter

125mm

φ125

Φ125mm

Weight

2700

3230

5000

Dimension

6.5m*3.3m*2.6m

8.9m*5m*2.65m

10m*4.7m*3.3m

Spportting leg dimension

3150mm×3150mm

4000mm×4000mm

4000mm
