Регистратор данных о температуре духовки с порошковым покрытием

Number of Channels

7-channel measuring external temperature, 1 channel measuring  the internal temperature of instrument

Temperature measurement range

0~500°C

Thermocouple

K

Memory

128 K

Resolution

0.3°C

Accuracy

0.5%

Instrument Size

Φ76 * 200

Temperature and time

continuous use under 200 °C about 120 minutes or continuous use under 300 °C about 60 minutes

Record Time

  7-channel full in 8 seconds record , can record 15 hours of data

Sampling rate

Sampling period:1s, 2s, 3s, 5s, 8s,10s,12s, 20s,40s, 60s

Cooler box size

280(L) x 120(W) x 100 (H)

Set Software

1)   Each channel can select or deselect

2)   When the calibration for each channel individually calibrated to ensure accuracy

3)   Optional sampling period

4)   Easy start / stop

Analysis Software

1)   Each curve optional display or not display;

2)   Heating rate can be calculated at any temperature between the two;

3)   can calculate above the temperature the four residence time;

4)   Peak temperature can be calculated ;

5)   2-5 compare test data;

6)   Report Print
