Metal analyzer spectrometer with high precision

Product Overview

Description

Metal analyzer spectrometer with high precision



Metal analyzer spectrometer  adhering to the Jiebo company over the years of high-quality traditional and decades of experience in development and design, and the integration of modern fashion design concept is Jiebo company launched the latest photomultiplier tube professional direct reading spectrometer. JB-750 Metal analyzer spectrometer is your best choice for the rapid and accurate analysis of solid metal samples in the laboratory.

JB-750 has been proved to be a mature and effective spectral analysis technology for 20 years. It has the characteristics of high sensitivity, high accuracy and long service life for solid metal samples.



Major Features:

1.Optical spectrometer the human oriented design, the standardized and modularized manufacture make the apparatussmaller.
2.The core components are all imported, which strengthen the stability and reliability of the apparatus.
3.We adopt the advanced foreign technologies of excitation source and design the excitation source of high energy, high stability by our own to fulfill the needs of ultrahigh content and trace analysis.
4.It adopts overall exit slit using technology which is convenient for choosing passage and regulating.
5.The high voltage of the PHT in the apparatus is controlled directly by computer and regulated by software, which improved efficiency of the passage.
6.In the apparatus, there is an automatic constant temperature system which solve the problem of bad effects to the optics system caused by changing temperature.
7.The multi-language operation software and flexible configuration enable the apparatus more humanistic.
8.This apparatus can analyze various kinds of matrix, such as Fe, Co, Ni, Ti, Cu, Al, Pb, Mg, Zn and Sn.



Adjuvant Equipments (self-prepared)
Argon
1. Two cylinders of high purity argon gas. (The purity degree>99.996%)
2. One YQY-6 Oxygen reducing valve.
3. One argon gas purifier.
Power supply
1. Electronic AC Power Supply(≥3KV, single phase 220V)
2. Independent exclusive Ground line, grounding resistance less than 2Ω,
Standard samples
Analyzing different materials, choosing curve samples and controlling curves.
Environmental equipment
1. Install air conditioner according to the size of the place laid the apparatus.
2. Install dehumidifier in humid areas.
3. One small vacuum cleaner.


Apparatus installation:
1. The Metal analyzer spectrometer installation should be guided by the engineers of our company.
2. Check the goods and packing list to affirm that they are qualified and the contents match the instructions.
3. Check whether or not the lab is qualified for using the apparatus.
4. Install and start the apparatus to check if everything works well.
5. Test and adjust according to the requirements on the technical contract. Make sure that the apparatus complies with the requirements.
6. Train the users, including: operate apparatus, use software of the apparatus and daily maintenances of the apparatus.


Equipment acceptance:
Choose one or two sets of national standard samples appointed by both parties and check the equipment ,Check and analyze the precision with repeated acceptance checking program and fill the installation and acceptance checking report.


After-sales service:
1. Metal analyzer spectrometer has a 12-month warranty since the date of install and inspection.
2. Beyond the warranty period, company will still provide after-sales service.
