Digital AC multifunction meter digital voltmeter

  Function

1.  Electric technical specification measurement(voltage, current, active power, energy).

2. Overload alarm (overload power, backlight and power flashing indicator).

3. Power alarm preset

4. Energy button reset

5. Energy lost data save

6. Large screen LCD full display(display current,voltage,power,energy at the same time)

7. Backlight

Display

1. Power: Test range 0~22KW

           <1KW display0.0~999.9W

           >1KW display1000~9999W

           ≥10KW display10.0~22.0KW

2. Energy: Test range 0~9999KWh

            ≥10KWh display10~9999KWh

3. Voltage: Test range 80~260V

                 Display 80~220V

4. Current: Test range 0-100A

                 Display 0.00~99.99A

Specification

1. Work voltage:80~260VAC

2. Test voltage: 80~260VAC

3. Rated power: 100A/22KW

4. Work Frequency: 45~65HZ

5. Accuracy: class 1.0

Dimension
