High quality online and Lab pH sensor electrode probe water sensor0 14pH

Product Overview

Description

Profession             Devotion            Concentration



    Nengshi  Analytical  Sensor  Co. , Ltd.  is  a  specialized  enterprise  engaged  in  research ,  development  and  manufacturing of analytical sensor.Through  accumulation  and practice more than twenty years, our annual output of sensor has reached more than 150,000 pieces. The quality of the products has been perfected and improved ceaselessly and the  products  have  made  the  company  win esteemed reputation from the wide users. At present, most of the products are exported to more than twenty countries , including  U.S.A, Canada, Brazil, France,  U.K,  Germany , Spain,  Russia,  Australia, Korea ,  Southeast Asia and  so  on. Meanwhile , we can  provide  OEM  products or produce the  products  accoding to the customers’ requirements.

    Our  company  owns  advanced   production   technology  and  perfect production  equipments. In  order  to ensure  the  quality  of the products, all of the raw materials for manufacturing the products are  under  the  continuous  monitoring  and  controlled  by the computer. The sensors strictly made by us with the latest  technology are widely used  in  various  chemical  detection  processes of  the  industrial  production, such as power, petrochemical industry,water and waste water  chemical industry, metallurgical  industry, biotechnology, food, beverage and so on.

Technical feature:

· Adoption of the most advanced Teflon diaphragm with large ring section make the electrode with stable liquid junction

· Quick response with high sensitivity, the measured value of 95% can be obtained in a few seconds

· The reference system is filled with high polymer; convenient to use and it is unnecessary to refill KCL solution

· pH range: 0-14pH, temperature range: 0-110 , pressure resistance: 0.6MP and zero potential E0=7pH

· The external dimensions of the electrode is 12 x 120, 150, 225mm or other length

· Unique structure preventing the electrode from easy pollution and blockage

· The electrode is suitable for various media with severe pollution and it can prevent the spread of S2-, NH4+ and CN-

· Plug-in connector; convenient for the installation and replacement of electrode

· It can be installed with the thread PG13.5

· Outer tube material: Glass or plastic outer tube

  Production feature

· Direct use with various pH meters as a complete set.

· Installation with 3/4NPT pipe thread, with safe and reliable sealing.

· Convenient to installation in form of flow-through or immersion.

· The sensor has the fixed cable and the length of the cable can be adjusted according to the requirements of the users.

· pH range:0-14; zero point: E₀=7pH; Temperature rang: 0-110℃.

· pressure range:0.6MPa.

· The external dimension of the sensor isΦ26×150.

· The outer tube material : PPS plastic.

· Sensitive material: Plane sensitive glass membrane, not easily broken.

· The thermistor is Pt100,Pt1000,2.252K,10K,22K etc.
