Product Overview

Description

Chemicals Hydrogenation 50L Jacketed Glass Reactor

Product Description

Chemical Hydrogenation 50L Jacketed Glass Reactor are commonly used for chemical synthesis, process development, workup, filtration, purification, evaporation, stirring, dissolving, mixing, and extracting operations across a host of scientific disciplines. Our Glass Reactor vessels range in size from 1 liter through 100 liters; everything from pilot scale and kilo-lab to commercial scale production.

Characteristics of Chemical Hydrogenation 50L Jacketed Glass Reactor:

1.Volume: 1L, 2L, 3L, 5L, 10L, 20L, 30L, 50L, 100L etc. Available in customized.
2.Reacting Temperature: -80~300℃
3. GG17, SS, mechanical sealing, KEDA brand.
4. University brands designated.
5. Explosion-proof device is optional.
6. AC Motor, brushless, no sparkle.
7. Constant rotating speed.

Chemicals Hydrogenation 50L Jacketed Glass Reactor

Technical Data

Model

S-2L

S-3L

S-5L

S-10L

S-20L

S-30L

S-50L

S-100L

Stirring

Power(w)

60

120

180

Stirring Speed(rpm)

0~600(Max. 1300)

Stirring

Shaft Diameter

12

15

Reaction

KettleCapacity(L)

2

3

5

10

20

30

50

100

Power Supply

220V  50/60 Hz

Motor Torque(g/cm)

2400

2400

4800

1000

1200

1200

1500

3000

Note

Floor type

304 all stainless frame

Explosion-proof

1. The stirring power (W): 180, 250, 370



2. Power supply: 220V / 50Hz or 110V / 60Hz

110 V/60Hz can be customized

Chemicals Hydrogenation 50L Jacketed Glass Reactor



Associated equipment

Associated equipment:

Chemicals Hydrogenation 50L Jacketed Glass Reactor
Other Types

Chemicals Hydrogenation 50L Jacketed Glass Reactor



Our Services

Why choose us!
-with 6 years foreign trade,and over 30 years domestic trade in China.
-we are professional mancufacturer in chemical industry!
-our main product is rotary evaporator, glass reactor, vacuum drying oven and their matched equipments.
-our customers are all over the world, mainly spread in America, Canada, India,and so on.

Warranty & Service:
Pre-service
24 Hours online service for your consult.
Help choose right model,and a series of service,person,advise.
Middle service
--Give you best offer
--Provide discount for many sets order
--Do customer's request:
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
After sale service
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Remote control technical consult
--Free installation DVD
--Maintenance plan

Chemicals Hydrogenation 50L Jacketed Glass Reactor

Packaging & Shipping

Packaging:
-The glass parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
Shipping:
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent.



Shipping methodNote
ExpressDoor to door, very convenient, don't need to clearance or pick-up
By air

Airport to airport, you need to do the customs clearance and pick up  the

goods at your local airport, which you can have a local shipping agent to do for you.

By seaPort to port and you need to do the customs clearance and pick-up the goods

at your local port, which you can have a local shipping agent to do for you.

Chemicals Hydrogenation 50L Jacketed Glass ReactorChemicals Hydrogenation 50L Jacketed Glass Reactor

Company Information

Company introduction:

Zhengzhou Keda Machinery and Instrument Equipment Co., Ltd. is specialized in R & D, production, sales, teaching and chemical biology pharmacy equipment integrated company. The main products are rotary evaporator, jacketed glass reactor, single layer glass reactor, circulating water vacuum pump, low temperature reaction bath (slot), low temperature cooling fluid circulating pump(cool chiller), vacuum drying oven, blast drying oven, freeze dryer, water/oil bath, magnetic heating stirrer, overhead mixer, ultrasonic cleaning machine, lift platform, etc. Besides, we act as agents of some domestic and foreign famous enterprise products, sustaining high praise in domestic junior colleges and universities, scientific research units, etc. Our products are sold to USA, Australia, Asia, Brazil, Iran, Egypt etc. countries and our customers have been fully affirmation.

Please click on the picture:

Chemicals Hydrogenation 50L Jacketed Glass Reactor

 Chemicals Hydrogenation 50L Jacketed Glass Reactor

enation 50L

FAQ

1. What's the max temperature?
Usually the high borosilicate glass can withstand over 300 degree centigrade and the PTFE stirring bar can withstand about 200 degree centigrade

2. What's the size do you have?
We can offer you 1L,2L,5L, 10L, 20L, 30L, 50L, 100L,150L.

3. How many kinds of your glass reactor?
Two types: jacketed glass reactor and single layer glass reactor.
Explosion proof is available

4. What’s the heating mode of single layer glass reactor?

Oil/water bath heating, and heating mantle.

5. Can you offer the supporting facilities?
Yes, we can offer you the vacuum, heating and cooling system as you demand.,

6. What's the minimum order quantity?
One set at present

7. What kind of payment term do you accept?
Normally we accept TT, Paypal, Western Union, Alibaba Escrow, and L/C. The exactly term with be discussed during the deal.

8. How will you delivery these goods?
It will be decided according to your quantity. Normally we will choose International Express, Air and Sea for small orders, we will send the goods by International Express like Fedex, DHL, TNT or UPS. Usually it takes 3-7 working days to arrive.
If big quantities we will ship by Ocean transportation, it takes one month to arrive. If urgent, you can select shipping by Air, but freight charge will be more expensive.

9. How will package glass equipment?
We package these glass equipment in good and Non fumigation standard wooden case.
