It is suitable for dyeing and washing fastness tests of knitted fabrics, woven fabrics, yarns, loose fibers, zippers, cotton, polyester, shoe material mesh, etc. It is designed for dyeing industry, chemical industry, textile colleges, raw materials, cloth The sample machine designed for the industry can accurately simulate the actual production conditions and achieve the desired effect.
Technical Data
This machine is an oil bath type infrared high temperature sample dyeing machine. It is a new high temperature sample dyeing machine which combines the advantages of traditional glycerol proofer and common infrared proofer. It is suitable for dyeing and weaving, woven cloth, yarn, cotton It is designed for dyeing industry, chemical industry, raw material and cloth industry. It can accurately simulate the actual production Conditions, to achieve the desired process results.
Specification
Model number
Desktop
Project
12/24
Number of cups
12/24
Highest dyeing temperature
135℃
Bath ratio
1:5-1:100
Heating power
4(6)×1.2kw,Blow light motor power is 25w
Heating medium
Oil bath heat transfer
Drive motor power
370w
Rotating speed
Frequency0-60r/min
Air - cooled motor power
200w
Dimensions
(12cups)670×670×770mm /(24cups) 860×680×780mm
Weight
120kg
Packing & Delivery
Certifications
FAQ
Q1:What material? A:Stainless steel SUS304; SUS316LQ2: What are the functions? A:Standard temperature standard function: Master cylinder water (pneumatic) Master cylinder drainage (pneumatic) Master cylinder heating (pneumatic) Master cylinder feeding (pneumatic) Tank agitation (motor) Tank drain (pneumatic) Feed water into the tank (manual) Tank heating (manual) Tank return (manual) Q3:product advantages Ultra-low energy design (Patent No.: ZL 201510276761.4; ZL201520349197.X), low water ratio dyeing (1:5-8) saves dye additives and steam. Use high-performance motor motor, low speed, low noise, low power consumption, energy saving, and achieve the highest economic benefits
Why Choose Us
Company Profile
Nantong East HeptanoicMachinery Co., Ltd. is located in taoyuan industrial zone, rugao software park, the longevity town, located in nantong city, north of the Yangtze river in the Yangtze river delta.The company specializes in the manufacture and development of textile printing and dyeing machinery equipment, is a private scientific and technological enterprise in jiangsu province and a high-tech enterprise in jiangsu province, enjoying a good reputation among peers in the industry.
Company has dyeing and mechanical industry more than technical staff, strong technical force, excellent processing equipment, advanced product technology, detection means complete, stable quality, reliable performance, products in addition to satisfy the masses of customers at home and abroad, also exported to other countries and regions of the world, with excellent quality, high-quality perfect after-sales service, wins the general customers trust and praise.
Specialized in high temperature, room temperature yarn dyeing machine development and manufacturing enterprises.Engaged in this field has more than 30 years of history, the main products are series of high temperature and high pressure DGHKS jet Hank dyeing machine, DGCKS series high temperature and high pressure cheese dyeing machine, DGAKS series of atmospheric pressure jet Hank dyeing machine, the bobbin DGRDKS high-speed dryer, DGSKS high temperature and high pressure vacuumalready set machine DGTYD tunnel Hank dryers and other products, is the domestic and foreign dyeing manufacturers the ideal choice.
The company is willing to first-class products and excellent after-sale service for new and old customers at home and abroad.
