Product Overview

Description


Product Description
Parameter:
\t
General Characteristic
\t
\t
Power
\t
9VBattery（6F22）
\t
LCD Size
\t
49mm×18mm
\t
Product Color
\t
Red +Grey
\t
Product Net Weight
\t
About 200g (Battery included）
\t
Product Size
\t
72mm×137mm×35mm
\t
Standard Accessories
\t
Test leads, Battery
\t
Standard Packing
\t
Giftbox, English Manual
\t
Standard Quantity Per Carton
\t
66 Pcs
\t
Standard Carton Measurement
\t
595mm×310mm×350mm
\t
Standard Carton Gross Weight
\t
About 22 Kg
Contrast:
\t
Specifications
\t
Range
\t
Best Accuracy
\t
Model
\t
\t
UT136A
\t
UT136B
\t
UT136C
\t
UT136D
\t
DC Voltage
\t
400mV/4V/40V/400V/500V
\t
±(0.8%+1)
\t
±(0.8%+1)
\t
±(0.8%+1)
\t
±(0.8%+1)
\t
AC Voltage
\t
400mV/4V/40V/400V/500V
\t
±(1.2%+3)
\t
±(1.2%+3)
\t
±(1.2%+3)
\t
±(1.2%+3)
\t
DC Current
\t
400uA/4mA/40mA/400mA/4A/10A
\t
±(1.0%+2)
\t
±(1.0%+2)
\t
±(1.0%+2)
\t
±(1.0%+2)
\t
AC Current
\t
400uA/4mA/40mA/400mA/4A/10A
\t
±(1.2%+5)
\t
±(1.2%+5)
\t
±(1.2%+5)
\t
±(1.2%+5)
\t
Resistance
\t
400Ω/4000Ω/40kΩ/400kΩ/4MΩ/40MΩ
\t
±(1.0%+2)
\t
±(1.0%+2)
\t
±(1.0%+2)
\t
±(1.0%+2)
\t
Capacitance
\t
4nF/40nF/400nF/4uF/40uF/100uF
\t
　
\t
±(4.0%+3)
\t
\t
\t
Temperature
\t
‘-40℃~1000℃
\t
\t
\t
±(2.5%+3)
\t
　
\t
Frequency
\t
10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz
\t
±(0.5%+3)
\t
±(0.5%+3)
\t
±(0.5%+3)
\t
±(0.5%+3)
\t
Duty Cycle
\t
0.1%∽99.9%
\t
√
\t
√
\t
√
\t
√
\t
Features
\t
\t
Diode
\t
\t
√
\t
√
\t
√
\t
√
\t
Continuity Buzzer
\t
\t
√
\t
√
\t
√
\t
√
\t
NCV
\t
\t
\t
\t
　
\t
√
\t
Auto Power Off
\t
\t
√
\t
√
\t
√
\t
√
\t
Low Battery Display
\t
\t
√
\t
√
\t
√
\t
√
\t
Input Impedance for Voltage Measurement
\t
≥10MΩ
\t
√
\t
√
\t
√
\t
√
\t
Data Hold
\t
\t
√
\t
√
\t
√
\t
√
\t
Max. Display
\t
\t
3999
\t
3999
\t
3999
\t
3999
\t
General Characteristic
\t
\t
Power
\t
9VBattery（6F22）
\t
\t
\t
\t
\t
LCD Size
\t
49mm×18mm
\t
\t
\t
\t
\t
Product Color
\t
Red +Grey
\t
\t
\t
\t
\t
Product Net Weight
\t
About 200g (Battery included）
\t
\t
\t
\t
\t
Product Size
\t
72mm×137mm×35mm
\t
\t
\t
\t
\t
Standard Accessories
\t
Test leads, Battery, Point type temperature probe(UT136C Only)
\t
\t
\t
\t
\t
Standard Packing
\t
Giftbox, English Manual
\t
\t
\t
\t
\t
Standard Quantity Per Carton
\t
66 Pcs
\t
\t
\t
\t
\t
Standard Carton Measurement
\t
595mm×310mm×350mm
\t
\t
\t
\t
\t
Standard Carton Gross Weight
\t
About 22 Kg
\t
\t
\t
\t
