DPB 250 блистерные упаковочные машины
- Category: Pharmaceutical Machinery >>>
- Supplier: Shanghai Pharmaceutical Machinery Co. Ltd.
Share on (60635762005):
Product Overview
Description
Product Overviews
Product Description
DPB 250 Blister Packaging Machines:
This machine is newest and high technology designed.It is suitable for packaging capsules,tablets,pills,chocolates,butter,biscuits,perfume,essence,facemasks etc with AL/PL,PL/PL materials.It is equipped with a micro-computer control system and frequency converter,with characterized by higher automation and easy operation.It is popular equipment for the foodstuff and cosmetics,particularly for those who are to make their own career.
DPB 250 Blistering Machines Blistering Machines Blister Packaging Machines Pharmaceutical Packaging Machine Features:
1.The distance can be adjusted freely in the same flat surface for forming,heat-sealing,perforation,punching parts etc.lt is suitable for various sizes of foodstuff packaging,and it has high precision and good Suitability.
2.Adjustable stroke,automatic feeding,register heating,positive presssure forming,up and down net web,cylinder heat-sealing,printing batch number with automatic perforation,mechanic dragging,easy operation,stable running.
3.It is adopted with imported gear reducer with lower noise and long life.
4.Correct location of die pressure plate,convenience of replacement.
5.Combination mechanism,convenient to assemble and disassemble,easy maintenance.
6.Equipped with temperature reserve chocolate feeder,it can ensure the chocolate charged smoothly,freeely and accurately.
Notes:1.lt can be added register sealing device with cursor trace.
All machines are customized. Please consult with our sales agents for detailed specification and quotation.
Technical Parameter
| Cutting Time(t/min) | Al-AL6-25,Al-plastic 6-50,Paper-plastic 6-50 |
| Max Production Capacity(ten thousand pics/h) | Al-Al≤11,Al-plastic≤23 |
| Max Forming Area And Depth(mm) | Al-Al 240*150*15,Al-plastic 240*150*26 |
| Stroke(mm) | 40-160(Can Be Manufactured As User's Requirements) |
| Standard Plat(mm) | 80*57(Can Be Manufactured As User's Requirements) |
| Air Pressure(Mpa) | 0.4-0.6 |
| Air Supply | ≥0.3m3/min |
| Total Power | 380V/22v 50Hz 6.2kw |
| Main Motor Power(KW) | 1.5 |
| Forming Aluminum(mm) | 0.10-0.15*250 |
| PVC Hard Pieces(mm) | 0.15-0.5*250 |
| PTP Aluminum Foil(mm) | 0.02-0.035*250 |
| Dialysis Paper(mm) | 50-100g*250 |
| Mould Cooling | Tap Water Or Circulating Water |
| Overall Dimensions(mm) | 3000*730*1600(L*W*H) |
| Weight(kg) | 1600 |
