PLD800 Concrete Batching machine

PLD Series Concrete Batching machine is a kind of equipment with automatically batching material on the front desk and using mixer together. It can automatically finishing the batching procedures of 3-6 kinds of materials (second grade concrete) such as sand, stone, cement according to users’ requirement. These serial products adopt electronic weighing, computer control, digital display, wired remote control operation, and have such advantages as accurate weighing, high precision batching, quick speed, strong control function and convenient operation. After this serial concrete batching machine with relative concrete mixer, different types and specification combined concrete mixing station can be formed.

Main Features

1) Professional team and perfect quality
2) Perfect service and after-sales service
3) Competitive and favorable price
4) Best precast concrete manufacturer in China
5) We accept different kinds of payment & trade terms if special countries
6) Different process and treatment for qiuck-wearing parts

\t
Product Model
\t
PLD600
\t
PLD800
\t
PLD1200A
\t
Weighing Hopper Volume m³
\t
0.6
\t
0.8
\t
1.2
\t
Storage Hopper Volume m³
\t
2X1.7
\t
2X2
\t
3X2.2
\t
Maximum Productivity m³/h
\t
36
\t
48
\t
60
\t
Batching Accuracy %
\t
±2
\t
±2
\t
±2
\t
Aggregate can be Equipped kinds
\t
2
\t
2-3
\t
3-4
\t
Feeding Height mm
\t
2000
\t
2364
\t
3900
\t
Total Power kw
\t
3.7
\t
6.6
\t
8.8
\t
Machine Weight kg
\t
2050
\t
2300
\t
3900
\t
Outline dimension (mm)
\t
3178X2150X2000
\t
5600X1830X2764
\t
8390X2000X2884
Our Company

Shandong Xingyu Mechanical Technology Co.Ltd, founded in 1996 and located in Zibo City, specialized in concrete prefabrication machine manufacture with a name brand of "Xingyu".
Our main products are JS Series Double shaft concrete mixer,PLD series aggregate batching and dispensing machines, LSY series cement screw conveyors and HZS/HLS series concrete mixing and batching plant. All these products have won great favor and popularity with more and more customers in domestic and oversea markets.

Our Service

We supply the technical supporting all the time.
We supply one year warranty for whole machine.
We supply free quick wear parts.
We supply low charge continue maintenance when warrenty is expired.
We supply free training to end-users
