Линия по производству экструзии пластиковых труб из ПВХ

Share on (60642940184):


Price:16 000,00 $

Quantity:


Product Overview

Description


Rigid PVC Plastic Pipe Extrusion Equipment


The  complete production line includes  the extruder/vauum tank/haul off machine/auto cutter/stack rack,the different diameter of pipe match with different extruders.



















































































































































Mode



Screw Dia.



Length to


 diameter



Rotational


Speed of screw



Height of center point



Capacity






Drive Power






 SJ-30/25CY



30mm



25:1



 10-160r/min



1000mm



  19.5kg/h



2.2kw,3kw



 SJ-45/25HY



45mm



25:1



 10-90r/min



1000mm



  22.5kg/h



5.5kw



 SJ-45/25CY



45mm



25:1



 16-160r/min



1000mm



  35kg/h



7.5kw,11kw



SJ-45/28CY



45mm



28:1



16-160r/min



1000mm



40kg/h



7.5kw,11kw



 SJ-45/25HY



45mm



25:1



 16-160r/min



1000mm



  35kg/h



11kw



 SJ-50/25HY



50mm



25:1



 16-160r/min



1000mm



  40kg/h



11kw,15kw



 SJ-65/25HY



65mm



25:1



 8-80r/min



1000mm



  100kg/h



18.5kw



 SJ-65/28CY



65mm



25:1



 15-120r/min



1000mm



  100kg/h



18.5kw,22kw



 SJ-65/28HY



65mm



28:1



 16-160r/min



1000mm



  120kg/h



22kw,30kw



 SJ-65/30CY



65mm



30:1



 15-120r/min



1000mm



  120kg/h



22kw,30kw,37kw



 SJ-65/34CY



65mm



34:1



 15-120r/min



1000mm



  120kg/h



22kw,30kw,37kw



 SJ-70/25HY



70mm



25:1



 8-80r/min



1000mm



  120kg/h



22kw



 SJ-90/25HY



90mm



25:1



 10-100r/min



1000mm



  155kg/h



30kw,45kw,55kw



 SJ-120HY



120mm



25:1



 30-90r/min



1000mm



  250kg/h



75k




Product Description


Rigid PVC Plastic Pipe Extrusion Equipment


The  complete production line includes  the extruder/vauum tank/haul off machine/auto cutter/stack rack,the different diameter of pipe match with different extruders.










Packaging & Shipping














Our Services





Machine warranty :


1: We have to run test machine before loading and then make samples for buyer to test.


2: When machine finished, and after testing final sample,If buyer are not satisfied with our


machine's performance, we would return back buyer's all deposit they had paid.


After sales service:


1. One year provides repair since after received goods.


2. If it is necessary to debug the machine in buyer's country. Buyer should afford


Round-trip expenses and worker's wage US$85/D,and supply accomodation for our staff.


3.The warranty period of the goods,Parts damaged with non-human factors will be


charged free.but human factors will be charged





Company Information


  Yuyao Guotai Rubber&plastic Machinery Co., Ltd is located in Ningbo city, Zhejiang Province in China. It is only 40km from Ningbo Airport, and it is around 200km far from ShanghaiAirport


Yuyao Guotai Rubber&plastics Machinery Co., Ltd was established in 2000 and has focused on plastic extrusion machinery for over 19years, we are a private high-tech enterprises integrated by R&D, manufacturing, selling, service and trading.
we
mainly produce plastic extrusion lines,such as:plastic Pipe extrusion line, plastic corrugated pipe extrusion line,plastic profile extrusion line, plastic sheet & board extrusion line, Rubber band extrusion line,soft PVC pipe extrusion line,plastic pencil extrusion line, plastic pelletizing and recycle line,and relative auxilary machines such as plastic hopper dryer,plastic color mixer,plastic crusher,auto loader,water cooling tower.


For over 19 years We have exported to many foreign countries, for exampleThe United states of America,Germany,Russia,Syria,Saudi Arabia,Turkey,South Africa,Pakistan,India,Indonesia,Vietnam,Phillippe,Morocco,Zmbia,Mauritius,Ghana,Egypt, Ethiopia, Vietnam, Chile, Brazil,Ecuador.and now more and more countries customers establish a good long-term business relationship with us. Our company with the purpose of mutual benefit, honest of the principles and purposes of the warm welcome mainland China various manufacturers and individuals to come to discuss the various forms of trade and economic cooperation.


We will always strive to keep forging ahead and making innovations. Meanwhile, we're willing to establish good relationships with both domestic and international customers to create new heights in the plastic machinery industry.





FAQ


Q: Your company is a trading company or an industrial manufacture factory?


A: We are an industrial manufacture factory. We have independent technical team who focus on making machines, all the products are made by our technical team.



Q:What is the ability of your factory?


A:About 300 set per year.





Q:Do you have any other services about your products?


A:We have a lot of experience on making projects and specifications for our clients, also we have a fixed service system.





Q:How do you make the quotation for clients?


A:Please offer the following information, so we can give you price and our advice as manufacturer:


1. Type of pipe you want to produce.


2. Pipe diameters.


3. Raw material and its types


If you can also send us photos of your samples, it would be highly appreciated.
