Серия 104, 16 контактов, WSO, коннектор под прямым углом, водонепроницаемые круглые коннекторы
- Category: Connectors and Accessories >>>
- Supplier: Shenzhen Raymo Electronics Technology Limited
Share on (60657548469):
Product Overview
Description
Product Description
RAYMO High performance push pull self locking connectors designed and tested to withstand extreme conditions
RM-F series
Plug models : S, SS, SC, SA, WSO, SFE
Socket model : D, DEE, DEU, DBPU, DBPE, DG, DBP, DBPLU, DBPLE, DBEE, DBEE,K, KE, KS, KSE,
Plug models : S, SS, SC, SA, WSO, SFE
Socket model : D, DEE, DEU, DBPU, DBPE, DG, DBP, DBPLU, DBPLE, DBEE, DBEE,K, KE, KS, KSE,
104 series 16 pin WSO right angle connector watertight circular connectors | ||||||||
Part No. | RM-WSO-2F1S-P19JS70 | |||||||
Size | Righ angle connector wso, male solder contacts,push pull connector, 19 pins | |||||||
IP Ranking | IP68 waterproof connector | |||||||
Contacts No. | 2 pin 3 pin 4 pin 5 pin 6 pin 7 pin 8 pin 10 pin 12 pin 14 pin 16 pin 19 pin | |||||||
Certification | ISO9001:2015, SGS, CE, ROHS, REACH | |||||||
Technical Characteristics | ||||||||
Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] | |||||
Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >96hr | |||||
Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] | |||||
IP Rating | IP50 | Certifications | ISO9001 CE ROHS2.0 SGS | |||||
Applications
RAYMO connectors applications
It is widely used for all kinds of medical equipment's, specially for the signal transmission, Medical Equipment ,Audio / Video, Camera, Testing and Measurement, Communications product line, military, Small HD Monitor, Sony CCD DXC XC-75 Camera, Sonosax, Surveying Instrument,Basler CCD AVT GIGE Industrial Camera etc.
Company
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED As manufacturer located in Shenzhen, focusing on manufacturing connectors and cable assemblies service more than 150 countries since 2010.
With several years experience in self researching and developing covers diversified connectors equivalent to binder, Lemos, Hirose, Odu, Fischers. well-known for sensor connector, military connector, AMC mini connector, waterproof connector, circular connector, industry connector and customized solution connector manufacturer, mainly in push pull connectors, sensor connector cables,circular aviation plug. And Also M8, M12, M16, 38999 etc ..Also the With professional enthusiasm, provides complete customer services, strong R&D capabilities and excellent product quality control.
Raymo Connectors is committed to working closely with its customers to equip their application with the most appropriate connector and cable system.Our product range comprises over 3,000 standard items and we are always prepared to develop customized solutions for specific requests.
Raymo Connectors is committed to working closely with its customers to equip their application with the most appropriate connector and cable system.Our product range comprises over 3,000 standard items and we are always prepared to develop customized solutions for specific requests.
Certifications
Exhibition
2017 Netherland IBC
2018 Germany Electronica
2019 Shanghai Testing Expo
Packing & Delivery
Normal packing details:
100PCS /carton
1: sample within 2-3 working days
2: QTY less than 1000pcs, 5-7 working days
Why Choose Us
1 | Lower price to save your cost |
2 | OEM or ODM accepted |
3 | Bend relief of plug are free |
4 | Free samples |
5 | Free cable solutions |
6 | Accept credit payment |
FAQ
Q1. Can I have a sample ?
Yes, we welcome sample order to test and check quality. Some samples are free, and some samples should be paid in advance and the cost will be refund after further order.
Q2. What about the production lead time?
We have stock, fast delivery below 5,000 pieces.
Q3. How do you ship the goods and how long does it take to arrive?
We often ship by DHL, UPS, FedEx,TNT,SF or EMS. It usually takes 3-5 days to arrive.
Q4. Is it OEM available?
Yes. We have rich experience and good ability to put your design and idea into real product, normally it take about 20 to 30 days for new product from mold design to final production.
