| Control system | The whole machine frequency conversion |
| Work station | All the English |
| Driving motor | Single frequency |
| Protective device | The machine protection |
| Cotton stripping | Stripper bar or roller |
| Mesh-out | 20-55m/min |
| Doff | 500mm*2 |
| Silling | 1230mm*1 |
| Product Keywords | polyester pet fiber making machines |
Uses and characteristics:
Suitable for carding of 1.5-20D*38-65mm artificial fibre.Single cylinder high-speed carding and double-doffer outputting has high production capacities.Cotton striopping has been used stripper bar or roller,the cotton feeding roller is controlled by frequency conversion with anti-metal protection device.
Main specifications:
Machine width:1550mm,1850mm,2000mm,2300mm,2500mm
Cylinder diameter: 850mm, 1020mm, 1230mm
Doffer diameter: 492mm, 535mm
Output speed:45m/min
Power:11.25-21kw
Technical Parameter | Dimension(L*W*H) | 4*3*2 |
Weight (kg)(Approx) | 6T | |
Machine width: | 1550mm,1850mm,2000mm,2300mm,2500mm
| |
Production capacities: | 160kg/h,180kg/h,200kg/h,220kg/h,240kg/h, | |
Power: | 11.25-21kw
| |
Power supply | 380V 50HZ |
