Система ОВКВ, нм, модулирующий тип, привод амортизатора дыма
- Category: HVAC Systems & Parts >>>
- Supplier: Soloon Controls (Beijing) Co. Ltd.
Share on (60672155796):
Product Overview
Description
Product Description
Technical Specification:
| Item | S6061SC/SF-2.5AF(S)/24V | |
| Torque | 2.5NM | |
| Damper Area | 0.5m2 | |
| Running Time | Motor 60~70s;Spring return 20S | |
| Power Supply | 24VAC/DC 50/60Hz | AC90~250V 50/60Hz |
| Operating Power Consumption | 2.5W | |
| Wire Size | 10VA | |
| Connection cable | 1m cable 2*0.75 m2 Auxiliary switch (F):1m cable 6*0.5 m2 | |
| Weight | 1.2kg | |
| Control Signal | 0~10V | |
| Angle of Rotation | 0~90°(max 93º) | |
Auxiliary Switch Rating | 3(1.5)Amp 250V | |
Life Cycle | >70000 | |
Noise Level | 50dB(A) and 62dB(A) | |
Electric level | Ⅲ | Ⅱ |
IP Protection | IP54 | |
Temperature | -20~+50℃ | |
Humidity | 5~95%RH | |
Storage Temperature | -40~+70℃ | |
| Certificate | CE & UL | |
Wiring diagram: Auxiliary switch:
Outline Size:
72℃ thermal sensor
