Chiller 50L-80C Low Temperature Cooling Alcohol Circulator Lab Refrigerated Chiller
DLSB -80c low temperature chiller are the true thermostatic control laboratory chiller, these closed laboratory chillers are ideal for applications such as cooling rotary evaporators, analytical instrumentation, laser etching, ICP, vacuum systems, plasma etching and jacketed reactors. This system can also be used as a replacement to tap water cooling in laboratory applications.Chiller 50L-80C Low Temperature Cooling Alcohol Circulator Lab Refrigerated Chiller
DLSB series -80c low temperature chiller are compressor-based recirculating chillers that offer outstanding performance and high reliability as well as quiet operation and ease-of-use. Powerful force/suction pump provides constant flow rates, while microprocessor PID controller gives you the ideal solution when you need precise temperature control or cooling below ambient temperature.
Chiller 50L-80C Low Temperature Cooling Alcohol Circulator Lab Refrigerated Chiller
Features of -80c low temperature chiller:
--No dry ice or liquid nitrogen needed
--Advanced PID digital temp controller
--Built-in chilling fluid filter protects the recirculating pump and prevent blockage
--All steel construction for durability
--Cost saving as the water consumption is completely eliminated
--Built-in casters for mobility
--Eco-friendly R404A refrigerant
--Insulated tubing included
Chiller 50L-80C Low Temperature Cooling Alcohol Circulator Lab Refrigerated Chiller
Specifications of -80c low temperature chiller:
Model
DLSB-5/80
DLSB-10/80
DLSB-20/80
DLSB-30/80
DLSB-50/80
DLSB-100/80
Volume (L)
5
10
20
30
50
100
Temp. Range
-80℃(zero load)--- Room temperature
Temp. Wave
±1℃
Cooling capacity (W)
200-1400
380-2600
600-2800
1870-4500
2300-6200
4800-11800
Flow Rate
20L/min
Lift Head
6-8m
8-10m
refrigerant
R404A
Power
Single phase 220V, 60Hz
Three phase 220V/380V, 60Hz
Rated Power(W)
1200
2600
3500
3500
14500
16000
Current (amp)
10
11.8
4.2
13
14.5
32
Mark
-10C, -20C, -30C, -60C, -80C, -120C is also available, customized chiller is also available
Detailed Images
