1. Suitable for grinding straight edge of different size and thickness flat glass. 2. The coarse grinding, fine grinding, clamfering and polishing can be finished at one time.
3. Working speed and working load can be adjusted smoothly by continuously variable
mechanism transmission.
4. Adjust front rail to match different glass thickness.
5. The machine is equipped with automatic clamping system and voltage stabilizing system.
6. It is a necessary tool with high precision, high efficiency and easy operation in glass
processing industry.
II. TECHNICAL SPECIFICATIONS:
TECHNICAL SPECIFICATIONS
voltage
Power
Min size
Max size
380v/50Hz
19.5kw
80x80mm
3000x3000mm
Glass thickness
Feeding speed
Weight of machine
Overall Size(LxWxH)
3-25mm
0.5-5m/min
2700kg
6300x1000x2500mm
Nude packing size: 2900*1000*1700mm
Wood packing size: 3200*1200*1800mm
Machine detail
1. CE machine & CE certification
PLC control system and digital displayer available;
2. Heavy duty foundation & beams: cast steel,annealing treatment;
3. Electric device: SIEMENS, Schneider or Delixi electrical optional;
ADDTECH GLASS MACHINERY CO., LTD. Was established in 2007. We are a professional manufacture which handling the deep-processed equipments of glass. The main products include: Glass Straight Line Edging Machine, Beveling Machine, Round Machine, Glass Washing Machine, Irregular Glass Grinding Machine, Glass Drilling Machine etc..
We are supplying the high quality products plus with best service. The automatic oil lubrication of pulling plate is our particular innovation, it is great helpful to improve stability and maintainability.
We are looking forward to be a valuable and strategic partner of you company, to help you thirve in the deep processed of glass industry.
