1.5 Inch Very Small Lcd Screen JHD144B2605
US $0.01-$1.00
Full Color Screen 2.8 size 240*320 LCD Module 2.8 inch TFT LCD Display
- Category: LCD Module >>>
- Supplier: Shenzhen Genyu Optical Co. Ltd.
Share on (60686915752):
Product Overview
Description
Full Color Screen 2.8 size 240*320 LCD Module 2.8 inch TFT LCD Display
Product Description
| Feature | |
| 1.LCD Type | 2.8"TFT LCD |
| 2.Display Mode | Normally white,Transmissive LCD |
| 3.Number of Pixels | 240(RGB) x 320 Dots |
| 4.Viewing Direction | 12:00 O’Clock |
| 5.Controller | LIL9341 |
| 6.Power Supply | 3.2V |
| 7.Operating Temperature | -20~+70℃ |
| 8.Storage Temperature | -30~+80℃ |
| 9.Pixel Arrangment | RGB vertical stripes |
| 10.Input signals | 16 Bit CPU I/F |
| 11.ROHS compliant | |
| Mechanical Parameters | |
| Item | Standard Value |
| Outline dimension: | 50×69.2×2.3 |
| Active Area | 43.2×57.6 |
| Electrical Characteristics | ||||
| Item | Symbol | Min | Typ | Max. |
| Power Supply for Logic | VDD | 2.6 | 2.8 | 3.0 |
| Input High voltage | Vih | 0.8VDD | -- | VDD |
| Input Low voltage | ViL | 0 | -- | 0.2VDD |
| Output High voltage | Voh | 0.8VDD | -- | -- |
| Output Low voltage | Vol | -- | -- | 0.2VDD |
| Power supply current | Idd | -- | -- | -- |
| Pin assignment | ||
| No. | Symbol | Function |
| 1 | GND | Ground |
| 2 | CS | Chip select input |
| 3 | SCL | Chip select |
| 4 | D/C | Serves as command or parameter selec |
| 5 | SDA | The data is applied on the rising edge of the SCL signal |
| 6 | SDD | Serial output signal. |
| 7 | GND | Ground |
| 8 | VCC | Power supply |
| 9 | IOVCC | Power supply |
| 10 | GND | Ground |
| 11 | A | Backlight anode |
| 12 | K1 | Backlight cathode |
| 13 | K2 | Backlight cathode |
| 14 | K3 | Backlight cathode |
| 15 | K4 | Backlight cathode |
| 16 | GND | Ground |
| 17 | NC | NC |
| 18 | NC | NC |
| 19 | NC | NC |
| 20 | NC | NC |
