Product Overview

Description


Product Description

PS INTERMITTENT ROTARY OFFSET PRESS

Model:FS360- 6C

1. Main technical specifications:

MAX.web width: 360㎜
MAX. printing width: 350㎜
MAX. printing length:350㎜
MIN. printing length: 175㎜
MIN. printing width: 100㎜
Max. Printing speed: 180Pcs(turns)/minute, or 10,000pcs(turns)/hour
Power: 380V/ 3 Phase; 33.6KW
DIMENSION: (L*W*H) L8850mm;W1600mm;H1850㎜
WEIGHT:18000KG


2. Main configuration:
\t
Item No.
\t
Item name
\t
Unit
\t
Quantity
\t
standard
\t
\t
\t
\t
1
\t
web unwinder
\t
unit
\t
1
\t
2
\t
auto web guider
\t
unit
\t
1
\t
3
\t
printing unit
\t
unit
\t
6
\t
4
\t
web rewinder
\t
unit
\t
1
\t
5
\t
UV dryers
\t
unit
\t
6
\t
6
\t
lamination/coating unit
\t
unit
\t
1
\t
7
\t
rubber blanket
\t
PCS
\t
6
\t
8
\t
printing rollers
\t
set
\t
6
\t
9
\t
tool box
\t
set
\t
1
\t
optional
\t
\t
1
\t
rotary die cutting unit
\t
unit
\t
1
\t
2
\t
video
\t
unit
\t
1
\t
3
\t
varnishing unit
\t
unit
\t
1
\t
4
\t
cold foil stamping unit
\t
unit
\t
1
\t
5
\t
corona treater
\t
unit
\t
1
\t
6
\t
flat silk screen printing unit
\t
unit
\t
1
\t
7
\t
remote control ink duck unit
\t
unit
\t
1

3. DETAILED TECHNICAL SPECIFICATIONS AND DESCRIPTION


Model FS360-6C is a high performance intermittent rotary offset, which is researched, developed and manufactured independently by Nickel Printing Machinery CO; LTD.

It is composed of unwinding/rewinding unit,PS plate offset printing units,UV drying units, web guider ,inking control system, water container, PS plate hole puncher, remote control ink duct, flexo printing unit, laminating unit and rotary die cutting unit,etc.



Key features:

a. The machine adopts the American PMAC motion control system. It is the most powerful , fastest, most reliable motion control system in the world, each unit is driven by an independent servo motor.

b. The machine adopts the most advanced German Technology Three-point Suspension Pressure Structure.

c. Shaftless turning: Every unit is driven by an independent servo motor.

d.\tregister system: Any movement (horizontal and vertical) of each unit is controlled by an independent servo motor.

e.\tAdopts high precision computer tracing device to ensure accurate front and back overprint, which increases the diversity of label printing.

f.\tEasy operation and fast pre-print preparation.

g.\tWeb automatic guiding.


Detailed descriptions:


\t
Item No.
\t
Item Name
\t
description
\t
1
\t
unwinding unit
\t
1 unit
\t
\t
Max. web unwinding diameter
\t
600 mm
\t
\t
Max. web width
\t
360 mm
\t
\t
Splicing table
\t
1 unit
\t
\t
Auto web guider
\t
1 unit
\t
2
\t
printing unit
\t
6 units
\t
\t
printing area
\t
350*350mm
\t
\t
PS plate size
\t
405*370*0.24mm
\t
\t
rubber blanket size
\t
500×370×1.95mm
\t
\t
Register adjustment: latitudinal
\t
±2mm
\t
\t
Register adjustment: longitudinal
\t
±10mm
\t
3
\t
UV dryers
\t
6 units
\t
\t
UV dryer power
\t
5 KW per unit
\t
4
\t
lamination unit
\t
1 unit
\t
5
\t
rewinding unit
\t
1 unit
\t
\t
Max. rewind diameter
\t
600 mm
\t
\t
tension controller
\t
1 unit
\t
6
\t
Varnishing unit(optional)
\t
\t
\t
Anilox roller
\t
1 pcs
\t
\t
Varnish roller
\t
1 pcs
\t
\t
Ink duct roller
\t
1 pcs
\t
\t
Ink duct roller
\t
1 pcs
\t
7
\t
Rotary die cut(optional)
\t
\t
\t
Magnetic roller
\t
1 pcs
\t
\t
Register adjustment: latitudinal
\t
±2.5 mm
\t
\t
Register adjustment:longitudinal
\t
±10 mm
\t
8
\t
Other devices
\t
\t
\t
PS plate hole puncher
\t
1 unit
\t
\t
Water container
\t
1 pcs
\t
\t
Inking control system(optional)
\t
1 unit
\t
\t
Air compressor(optional)
\t
0.6-0.7KPa
\t
10
\t
Machine color
\t
standard



suitable materials:
self-adhisive paper/pvc/pet/opp,polyster film,laminate tubes,flexible packaging material,etc
Thickness of substrate: 70g-350g
suitable ink: UV ink only

suitable printing plate: PS plate


.Auxiliary Facilities(Prepared by Customer)
1)\tPower source:3 phase 4 wires,380V 50Hz
2)\tmain power Cable size: 3×25㎜²;N:1×10㎜²;PE:1×10²
3)\tair compressor: 0.6-0.7KPa

Our Service
CE Certifications
Exhibitions
Applications
Trade terms

Quotation validity:120 days
Delivery time:120 days after the deposit payment received by the seller
Country of Origin and manufacturer: NICKEL PRINTING MACHINERY CO.,LTD P.R.CHINA
Port of Shipment: Guangzhou or Shenzhen

PAYMENT TERMS:
●\t30% advanced T/T
●\t60% by T/T before shipment or irrevocable L/C at sight.
●\t10% by T/T in a week after signing acceptance report for installation and testing.10%
GUARANTEE:12 months starting from the date of signing Acceptance report for installation and Commissioning.
Installation and commissioning in the buyer's factory.
●\tThe seller's engineers' salaries are for the seller's account;
●\tThe seller's engineers' traveling, boarding,lodging costs and air tickets are for the buyer's account

FAQ


Q:  Are you factory or trading company?

A: We are professional manufacturer of label printing machine for over 20 years

Q: How about your after service?

A: We have a after sales team to fully support after service. our after sales service includes hotline, new machine installation, warranty maintanence&repair, life-long technique support.

Q: where is your factory?

A:our factory is in Guangzhou city, China, near Hongkong. 1 hour's drive from Guangzhou airport.
