CENTER-252 AC CLAMP METER


 Specifications


CENTER-252, True-RMS, INRUSH Current Analysis



 CENTER-252, True-RMS, INRUSH Current Analysis


When you need to analyze the INRUSH current of electric motors or other devices, CENTER 252 delivers the solution. With 0.01A high resolution to measure up to 660A AC current, the CENTER 252 is ideal tool for general purpose applications. Built-in backlit LCD, True-RMS, rated 600V CAT III, it’s not only easy, convenient, but also safe to use.









































































































Model



252







AC/DC



True RMS



YES



Clamping diameter



25 mm



Autorange



YES



Backlit LCD



YES



Current



AC



Range



0.01 to 600.0 A



Accuracy



1.9% rdg + 5 dgts



DC



Range



0.01 to 600.0 A



Accuracy



2% rdg + 5 dgts



Voltage



AC



Range



0.1 to 600.0 V



Accuracy



1.2% rdg + 5 dgts



DC



Range



0.1 to 600.0 V



Accuracy



1% rdg + 2 dgts



Ohm



0.1 Ω to 1.000 kΩ



Continuity



< 40 Ω



Peak



YES



Hold



YES



Auto power off



YES



Electrical safety rating



600V CAT III



Battery



2 x AAA 1.5V



Dimensions & Weight



209x74x36mm/255g





The batteries not included package
