Granite Marble Stone Block Squaring Cutting Machine

Product Overview

Description

GBLM-1500 Gantry Type Block Leveling Squaring Machine

Features:

1-     It is used to process arm stone with excellent quality, like tomb stone.

2-     It uses the imported frequency converter to conduct step less speed adjustment.

3-     The cutting table can rotate in 360°degrees by manual to achieve the shape cutting.

4-     It is provided with a heavy type trolley to conduct leveling on blank materials.



Technical Data:

Name	Unit	GBLM-2500	GBLM-1500
Blade diameter	mm	¢2500	¢800, ¢1500, ¢2200
Blade vertical stroke	mm	1450	2000
Max cutting size	mm	3000×1800×1050	3000×1800×2000
Water consumption	m3/min	8	8
Main motor power	kw	30	30
Dimensions(L×W×H)	mm	5000×5800×5400	5000×5800×5800
Weight	kg	≈10000	10500



Guarantee & after sale service:
1) Warranty for half year. Extra fee is paid if out of date. Any damage to the machine caused by improper use will be charged.
2) when receiving the 30% down payment, we will prepare machine for you, it will take 2-5 weeks, to get the shipping pictures for you.
3) 24-hour technical support Internet or by Telephone, free instructions and Problem solving.

FAQ:
1, How to pay to you?
T/T in advance We accept 30% deposit, 70% before shipment
2, How long is the delivery time?
For standard machines, it would be 2-5 weeks; For non-standard machines and customized machines according to client s specific requirements, it would be 10 days longer.
3, Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you.
4, How about the documents after shipment?
After shipment, we will send all original documents to you by DHL or Tele-Release, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
5, What is the packing?
Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package
Save space as much as possible for container loading.
