High Quality Efficient Quarry Stone Block Cutting Machine For Sale
- Category: >>>
- Supplier: Xiamen Great Base Co. Ltd.
Share on (60707672315):
Product Overview
Description
Features:
1-It adopts a large-span bridge type end beam structure. The principal axis system adopts 2-stage deceleration mechanism, thus increasing the principal axis working torque. The up-down adopts a hydraulic system to carry out stable high-speed cutter raising and low-speed cutter feeding (sawing requirements). The large block can be put directly on the ground, thus increasing the processing stability and saving machine maintenance costs greatly.
2-We use the sliding plate structure which is better than four pillars structure. The supplier of four pillars structure will increase the weight of the machine; they will fill cement in the four pillars. With our structure, there is no place to fill the cement, so we need to increase the weight of the sliding plate itself so that we can make sure that our material is true. This is very important for the life of the machine.
3-It is use the PLC controlling system which can increase the cutting precision and achieve fully auto cutting.
Specifications:
Name | Unit | GBQQJ-3000A | GBQQH-3000B | GBQQJ-3500 |
Blade diameter | mm | Total 6pcs, Max. ¢3000 | Total 6pcs, Max. ¢3000 | Total 6pcs, Max.¢3500 |
Max. cutting size | mm | 2700*2300*1300 | 3500*2300*1300 | 3000*2300*1500 |
Main motor power | kw | 55 | 55 | 55 |
Girder length | mm | 7500 | 8700 | 8700 |
Water consumption | m3/h | 12 | 12 | 15 |
Weight | kg | 13000 | 13500 | 16000 |
Guarantee & after sale service:
1) Warranty for half year. Extra fee is paid if out of date. Any damage to the machine caused by improper use will be charged.
2) when receiving the 30% down payment, we will prepare machine for you, it will take 2-5 weeks, to get the shipping pictures for you.
3) 24-hour technical support Internet or by Telephone, free instructions and Problem solving.
FAQ:
1, How to pay to you?
T/T in advance We accept 30% deposit, 70% before shipment
2, How long is the delivery time?
For standard machines, it would be 2-5 weeks; For non-standard machines and customized machines according to client s specific requirements, it would be 10 days longer.
3, Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you.
4, How about the documents after shipment?
After shipment, we will send all original documents to you by DHL or Tele-Release, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
5, What is the packing?
Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package
Save space as much as possible for container loading.
Worktable can be ordered
