Granite Marble Stone Polishing Grinding Machine

Product Overview

Description

Features:

This machine is mainly applied to grind and polish marble and granite slabs. It is mainly suitable for coarse grinding, fine grinding and polishing marble and granite slabs. Being pendulum which is advanced internationally now days, the grinding heads are controlled by air cylinder to elevate. Their longitudinal and transverse movements are enabled by cyclical pinwheel reduction motor. Having a PC programmer inside the electrical cabinet, it can grind the slabs in the way of longitudinal wave, transverse wave and cycle wave. Therefore, it features low cost and high grinding efficiency.

Technical Data:

Name	Unit	QSM-110	QSM-200
Max. processing size	mm	3000*1100	3200*2000
Max. thickness of slabs	mm	60	60
No. of grinding heads	pc	1	1
Lateral running speed of grinding head	Mm/min	3780	3780
Lateral running speed of working table	Mm/min	3300	3300
Main motor power	kw	11	11
Overall dimension(L*W*H)	mm	4500*2400*2100	4500*4340*2420
Total weight	kg	2700	4200
Air consumption	m³/min	0.1	0.1



































Guarantee & after sale service:
1) Warranty for half year. Extra fee is paid if out of date. Any damage to the machine caused by improper use will be charged.
2) when receiving the 30% down payment, we will prepare machine for you, it will take 2-5 weeks, to get the shipping pictures for you.
3) 24-hour technical support Internet or by Telephone, free instructions and Problem solving.

FAQ:
1, How to pay to you?
T/T in advance We accept 30% deposit, 70% before shipment
2, How long is the delivery time?
For standard machines, it would be 2-5 weeks; For non-standard machines and customized machines according to client s specific requirements, it would be 10 days longer.
3, Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you.
4, How about the documents after shipment?
After shipment, we will send all original documents to you by DHL or Tele-Release, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
5, What is the packing?
Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package
Save space as much as possible for container loading.
