Full Automatic Pet Blow Machine Auto Bottle Blowing Machine
US $13000-$30000
Factory price 5 gallon bottle blowing machine/top quality barrel bucket blowing machine price
- Category: Stretch Blow Moulding Machines >>>
- Supplier: Zhangjiagang Sanofi Machinery Co. Ltd.
Share on (60721858243):
Product Overview
Description
Products Description
Factory price 5 gallon bottle blowing machine/top quality barrel bucket blowing machine price
semi automatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from
18L-20L. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle etc.
1.Adopting double crank to adjust mould ,heavy locking mould, stable and fast ,Adopt infrared oven to heat the perform ,the perform rotated and heated equally.
2.The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow .It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.
3.The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
4.The machine can be operated in the step-by-step mode and the semi-auto mode.
5.The machine is small with low investment, easy and safe to operate .
18L-20L. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle etc.
1.Adopting double crank to adjust mould ,heavy locking mould, stable and fast ,Adopt infrared oven to heat the perform ,the perform rotated and heated equally.
2.The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow .It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.
3.The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
4.The machine can be operated in the step-by-step mode and the semi-auto mode.
5.The machine is small with low investment, easy and safe to operate .
Details Images
Theoretical output | 90pcs per hour |
Max. mould plate Dimension(L x W) | 400x450mm |
Max.mould thickness: | 370mm |
Clamping force: | 150KN |
Mould opening stroke | 350mm |
Blowing Air Pressure | ≤3.0 Mpa |
Working Pressure | ≤1.0mpa |
Main machine (L x W x H) | 1900*800*1600(mm) |
Main machine weight | 500Kg |
Heater weight | 450Kg |
Power | 14 kw |
High Pressure Air Compressor
Brand: Shangair
Model:1.2m³/30bar
Air discharge:1.2m3/min
Working pressure:3.0MPA
Motor power:11kw
Storge tank:150L
Motor running speed:620R.P.M
Weight:600kg
Packing dimension:1900*1000*13mm
Semi automatic bottle making blow molding machine for pet bottle
Model:1.2m³/30bar
Air discharge:1.2m3/min
Working pressure:3.0MPA
Motor power:11kw
Storge tank:150L
Motor running speed:620R.P.M
Weight:600kg
Packing dimension:1900*1000*13mm
Semi automatic bottle making blow molding machine for pet bottle
Air filter
Rated air flow:1.0m³/min
Rated working pressure:3.0Mpa
Input air temperature: ≤80ºC
Filtering precision: 1μm
Oil content: 1ppm
Weight: 40kg
Size: 300mm×300mm×750mm
Semi automatic bottle making blow molding machine for pet bottle
Rated working pressure:3.0Mpa
Input air temperature: ≤80ºC
Filtering precision: 1μm
Oil content: 1ppm
Weight: 40kg
Size: 300mm×300mm×750mm
Semi automatic bottle making blow molding machine for pet bottle
Bottle Blowing Parts
Unique heating system, accurate temperature control and easy adjustment.
Unique air storage unit.
The cooling system achieves the desired cooling effect.
Each action is driven by a cylinder instead of an oil pump, without contamination.
Semi automatic bottle making blow molding machine for pet bottle
Unique air storage unit.
The cooling system achieves the desired cooling effect.
Each action is driven by a cylinder instead of an oil pump, without contamination.
Semi automatic bottle making blow molding machine for pet bottle
Recommend Products
Product packaging
After Sales service
*We can send you the video of mechanical operation.
*Welcome to our company, we can show you the equipment in our factory. If you come to China and don't know the location of our
company, you can contact us to pick you up.
*We can design the machines according your requirements.(material ,power,filling type,the kinds of the bottles,and so on
*Professional engineers come to install and debug the machine, and train relevant operators until they can operate the machine
skillfully
*Welcome to our company, we can show you the equipment in our factory. If you come to China and don't know the location of our
company, you can contact us to pick you up.
*We can design the machines according your requirements.(material ,power,filling type,the kinds of the bottles,and so on
*Professional engineers come to install and debug the machine, and train relevant operators until they can operate the machine
skillfully
