900 1800 2100 2600 3G 4G LTE ретранслятор усилитель для домашнего использования
- Category: Repeaters >>>
- Supplier: Shenzhen Xinlun Communication Technology Co. Limited
Share on (60734332076):
Product Overview
Description
Product Description
GSM/3G/LTE 900 2100 2600 MHz Triple Band Mobile Signal Booster Repeater
Technical Specifications:
Electrical Specifications | |||
Frequency Range
| Uplink | Downlink | |
890MHz~915MHz/ 1920MHz~1980MHz/ 2500-2570MHz | 935MHZ~960MHz/ 2110MHz~2170MHz/ 2620-2690MHz | ||
Output Power | 20±2dBm | 23±2dBm | |
Gain | 70±3dB | 75±3dB | |
Bandwidth | Wide Band | ||
Ripple in Band | ≤5dB | ||
VSWR | ≤2 | ||
Noise Figure@ max. gain | ≤5.0dB | ||
Impedance | 50 Ohm | ||
Power Supply | AC:100~260V, 50/ 60Hz;DC:12V 3A | ||
Intermodulation Products | 9KHz~1GHz | ≤ -36 dBm | |
1GHz~12.75GHz | ≤ -30 dBm | ||
Spurious Emission | 9KHz~1GHz | ≤ -36 dBm | |
1GHz~12.75GHz | ≤ -30 dBm | ||
Mechanical Specification | |||
Connector | N-F | ||
Cooling | Heatsink Convection cooling | ||
Weight | 1.4kg | ||
Size | 250mm*190mm*22mm | ||
Installation Type | Wall Installation | ||
Coverage | 1500~2000m2 | ||
Color | Blue | ||
Detailed Images
Accessories
a.one tri band signal booster;
b.one indoor antenna;
c.one outdoor antenna;
d.10meter cable and 3meter cable;
e.User manual;
f.power adapter.
Packaging & Shipping
1.Packaging:paper box
2.Delivery time:in a week after payment
3.Shipping ways:DHL/UPS/FEDEX/EMS etc.
4.Payment ways:T/T,Western Union,Paypal.
Our Services
1.Your inquiry related to our products or prices will be replied in 24hours;
2.Well-trained and experienced staffs to answer all your inquiries in fluent English;
3.Monthly output over 2000pcs;
4.Strong package;
5. Sample order in small quantity is acceptable;
