XK-450 EPDM NR SBR rubber open mixing mill with bearing bush
US $3000-$50000
Rubber Refining Mill / Rubber Refiner Mill Machine
- Category: Rubber Two-Roll Mills >>>
- Supplier: Qingdao Toplit Industry Co. Ltd.
Share on (60738806004):
Product Overview
Description
Rubber Refining Mill / Rubber Refiner Mill Machine
WhatsApp 0086 15063906282
Main Technical Spec:
| Type | XKJ-450 * 800/1000 | XKJ-480 * 1000 |
| Diameter of front & rear roller | 450mm/510mm | 480mm/610mm |
| Working length of rollers | 800mm/1000mm | 1000mm |
| Roller materials & structure | Chilled casted iron & smooth roller | Chilled casted iron & smooth roller |
| Rotation speed of front roller | 30.6m/min | 32.9m/min |
| Motor Power | 55KW/75KW | 75KW/90KW |
| Speed reducer | Hardened teeth speed reducer | Hardened teeth speed reducer |
| Roller support type | Bearings | Bearings |
| Lubricating type | Grease lubricating | Grease lubricating |
| Weight | 10tons | 16.5tons |
Application: The machine is mainly used for refining of reclaimed rubber and rubber sheeting.
The rollers are made of chilled cast iron with wear-resistant hard surfaces. The two rollers are smooth ones with bored cavities and can be cooled homogeneously. The protective device is provided to protect the main parts from damage due to overload. In case of emergency, the safety rod is pulled down and the rollers will be stopped immediately.
Contact: Sharon at qdtoplit dot com
WhatsApp/ Tel/ Wechat: 0086 15063906282
Porduct Photos
