Round brush making machine for industrial brush

Product Overview

Description

3 axis drilling & tufting machine, specially for hair brushes.
Brush making machine have been sold to more than 23 countries in the world!



Diameter of drilling holes: 3.0 to 6.0mm
Depth of drilling holes: 0 to 12mm
Production speed: 540-600 holes/minute
Tufting mode: Staple mode
Length of bristle (unfolded): 10 to 240mm
X-Y-H itinerary: 25

0mm-200mm
Z itinerary: 360 °
Bristle container: double color
Maximum store holes: 8,000
For using transducer and brake motor, the motor speed can be adjusted optionally
Suitable for plastic, wooden, coppery, aluminous and ferric brush handles
Easy to change design, only need to change gripper
Holes distribution can be freely designed
Size of machine: 1,720 x 1,270 x 1,200mm
Net weight: 560kg
