1.5 Inch Very Small Lcd Screen JHD144B2605
US $0.01-$1.00
2,0 дюймовая панель ЖК экрана 240*320 с интерфейсом SPI mini ips tft
- Category: LCD Module >>>
- Supplier: Shenzhen Chance Technology Co. Ltd.
Share on (60768895104):
Product Overview
Description
Product Description
Parameters
| Item | Specification |
| Display Mode | Normally Black,Transmissive |
| Display Technology | α-Si TFT active matrix |
| Outline Dimension | 34.60(H) X 47.80(V) X 1.90(T) mm |
| Active Area | 30.6 (H) X 40.8 (V) mm |
| Resolution | 240X(RGB)X320 dots |
| Pixel Pitch | 0.1275X0.1275 mm |
| Pixel Configuration | RGB Stripe |
| Backlight | White LED |
| Luminance | (250)(Min.) cd/m2 |
| Surface Treatment | Anti-Glare |
| Driver IC | ST7789V |
| Viewing Direction | All |
Pin
| Pin No. | Symbol | I/O or connect to | Description | When not in use |
| 1 | LEDA | LED DRIVER | Backlight anode. | - |
| 2 | LEDK | LED DRIVER | This pin is used to be serial interface clock. | - |
| 3 | GND | PWR SUPPLY | POWER GROUND. | - |
| 4 | RESET | I/O | Reset pin. | - |
| 5 | TE | I/O | Tearing effect signal. | - |
| 6 | RS/DCX | I/O | Display data/command selection pin in 4-line serial interface. | GND/IOVCC |
| 7 | SCLK | I/O | The serial interface clock signal. | GND/IOVCC |
| 8 | SDA | I/O | SPI interface input/output pin. | GND/IOVCC |
| 9 | CS | I/O | Chip select signal. | GND/IOVCC |
| 10 | GND | PWR SUPPLY | POWER GROUND. | - |
| 11 | IOVCC | PWR SUPPLY | Interface power supply,1.65v~3.3V. | - |
| 12 | VCC | PWR SUPPLY | Analog power supply, 2.5V~3.3V. | - |
| 13 | GND | PWR SUPPLY | POWER GROUND. | - |
| 14 | NC | - | No connect. | - |
| 15 | GND | PWR SUPPLY | Backlight cathode. |
Drawing
