Product Overview

Description

FH230C cone winder

It is mainly used to spooling  after the nylon and other elater winder which are dyinged. It also can he made to measure.
Technical parameters:
1.Form :single face/double face
2.distence :360mm
3.spindle : 12.24.48 spindles
4.output :8-10 kg/spindle 24 hours
5.size of Tube : straight-edge bobbin , cone bobbin (150-290mm)
6.motor power :  0.37 kilowatt/ 12 spindles
7.Overall dimension : 12 spindles : length :4300mm
                                                              breadth : 500mm
                                                              height : 1700mm

 It is suitable for various kinds of raw materials, such as chemical silk,artificial silk, gold and silver silk, deformation silk, easy operation, easy maintains. Can produce according to our customer's request .



Number of spindles	12 spindles(optional)
Spindle gauge	360mm
Dimensions	L4300mm x W500mm x H1700mm ( 12 spindles)
Cylindrical assembly wound package	See the sample tube from the customer
Form of operation	single side or double sides
Power	370w/12spindles
productivity	8kg-10kg/spindle(within 24 hours)
bobbin type	flat bobbin or Pagoda tube(optional)
bobbin length	150-290mm
