Factory Split Wall Mounted Air Conditioner wholesale

| Name | swimming pool heat pump |
| Function | spa or pool water heater and dehumidifier |
| COP | 4.0~4.5 |
| constant temperature | 28-29℃ |
| heat exchanger | titanium heat exchanger |
| Max temperature | 40'C |
| Heating capacity | 65KW |
| Rated temperature | 28'C |
| Refrigerant | R410A |
| Warranty | 1year |
| Product Keywords | Mini swimming pool heat pump,Small swimming pool heat pump,2.5kW swimming pool heat pump |
BLUEWAY Swimming Pool Heat pumps are specially designed and engineered for water temperature control of swimming pool and spa. The pool Heat Pump units can work as chillers in summer and heat pumps in other seasons, offering the most energy efficient pool & spa chilling and heating. Compared to gas, oil, or electric heaters, operation cost of swimming pool water chiller & heat pumps is up to 60%~80% less, saving your expenses in energy costs each year. Blueway Swimming Pool Heat Pump is especially suitable for the small household swimming pool Heating.
Products feature:
1) PVC Titanium heat exchanger with full resistance against corrosion, more durable.
2) Compact structure, easy demount-able for access.
3) High efficiency compressor with R410a or R32 refrigerant..
4) Flow switch for water flow protection.
5) Intelligent controller and adjustment by quick mind microprocessor.
6) Intelligent LCD display wire controller with touch screen display.
7) Air exchanger (fins-coil) with hydrophilic coating.
8) Automatic defrosting function included. (With reverse cycle valve inside)
9) General testing and operational test carried out for every unit before package in the factory.
10)50Hz and 60Hz units all available.

| Model | BHP | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | 100 | 120 | 160 | ||
| Power Suplly | V/P/Hz | 380-415/3/50 or 208-2303/60 | ||||||||||||
| Output | Cooling | kW/h | 25 | 33 | 41 | 51 | 65 | 82 | 97 | 131 | 163 | 192 | 241 | |
| Heating | kW/h | 30 | 39 | 47 | 60 | 78 | 106 | 128 | 170 | 214 | 243 | 280 | ||
| Dehumidification capacity | Kg/h | 17 | 22 | 26 | 33 | 43 | 51 | 62 | 84 | 102 | 122 | 160 | ||
| Application pool surface area | m² | 68 | 88 | 104 | 132 | 172 | 204 | 248 | 336 | 408 | 488 | 640 | ||
| Rated Airflow | m3 @300Pa | 4000 | 5000 | 6000 | 7500 | 9000 | 11000 | 13000 | 16600 | 21000 | 25000 | 32000 | ||
| Blower | Qty | Nos. | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | |
| Type | - | Centrifugal | ||||||||||||
| Static pressure range | Pa | 100-500 | 100-500 | 100-500 | 100-500 | 100-850 | 100-850 | 100-850 | 100-850 | 100-850 | 100-850 | 100-850 | ||
| Power input | KW | 1.5 | 1.5 | 2.2 | 2.2 | 3.5 | 4 | 5.5 | 6 | 7 | 7.5 | 11 | ||
| Compressor | Qty | Nos. | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 or 4 | 2 or 4 | 2 or 4 | 2 or 4 | |
| Type | Scroll | |||||||||||||
| Power input | KW | 5.5 | 7 | 8.5 | 5.4 | 7 | 8.5 | 11 | 7 or 13 | 8.5 or 16.5 | 11 or 22 | 13 or 25 | ||
| Water Heat Exchanger Condenser | Type | - | Titanium Tube in PVC Shell | |||||||||||
| Rated working pressure | Mpa | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | ||
| Max.water temp. | ℃ | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 | ||
| Rated water flow rate | m3 | 4.7 | 6.1 | 7.2 | 9.4 | 12.2 | 14.5 | 18.8 | 24.6 | 30.6 | 37.5 | 48 | ||
| Water connection size | mm | 32 | 32 | 38 | 50 | 50 | 63 | 63 | 75 | 75 | 90 | 100 | ||
| Air Cooled Condenser | Qty | Nos. | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | |
| Rated capacity | KW | 30 | 39 | 47 | 60 | 78 | 96 | 118 | 150 | 184 | 223 | 278 | ||
| Rated airflow | m3 | 10000 | 12000 | 15000 | 20000 | 24000 | 30000 | 40000 | 48000 | 60000 | 80000 | 90000 | ||
| Nos. of fan | Nos. | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 4 | 4 | 4 | 4 | ||
| Fan motor power input | KW | 0.82 | 0.82 | 1.65 | 0.82 | 0.82 | 0.82 | 0.82 | 0.82 | 0.82 | 1.1 | 1.1 | ||
| Dimension | Outdoor condenser | W | mm | 706 | 1450 | 1450 | 1450 | 1800 | 1850 | 2110 | 1800 | 1850 | 2110 | 2500 |
| D | mm | 686 | 705 | 705 | 705 | 705 | 1000 | 1100 | 1000 | 1000 | 1100 | 1200 | ||
| H | mm | 940 | 1065 | 1065 | 1065 | 1065 | 1320 | 1350 | 1320 | 1320 | 1350 | 1350 | ||
| Indoor main unit | W | mm | 3600 | 3800 | 3600 | 3800 | 4200 | 4600 | 4900 | 5400 | 5800 | 6600 | 7000 | |
| D | mm | 1370 | 1520 | 1570 | 1670 | 1670 | 1930 | 2160 | 2200 | 2200 | 2150 | 2200 | ||
| H | mm | 1160 | 1160 | 1260 | 1360 | 1450 | 1520 | 1690 | 1840 | 2150 | 2200 | 2500 | ||
| Indoor Main Unit Weight | Kg | 500 | 800 | 900 | 1200 | 1500 | 1650 | 1850 | 2200 | 2500 | 2700 | 3300 | ||
| Notes: | ||||||||||||||
BLUEWAY was originated founded in Australia in 1993. It has earned a worldwide reputation in the field of liquid heating and cooling systems (chillers & heat pumps) through about 20 years experience in HVAC industry.
In 2007, Blueway established its subsidiary manufacturer in Shunde, Foshan of China, utilizing the manufacturing advantages here and supplying chillers and heat pumps worldwide
Establish Blueway China Manufacturing base in Shunde, Foshan China
Start Export Heat Pump products to EU countries, get clients good reputation
Become official partner for Universiade Shenzhen; Become Hilton qualified partner for indoor pool AHU, Pool Heat pump supplier
BLUEWAY R32 EVI +Inverter heat pump Get ErP A++ Certificate from TUV
BLUEWAY Expand our production line to AHU, Fresh Air units, VRF and other HVAC related products
28 Years experience in HVAC Industry
We promise to response within 24 Hours
More than 30 staff R&D Team, which enable us to provide package solution for clients
Blueway have got CE, ErP A+ and A++ certificate from TUV.
