linde forklift matching joystick 7919040041 7919040042

Product Configuration

No.

Project

Content

1

Industrial

SJ500 Industrial Joystick

2

Operation Direction

 T-automatic spring return

3

Operation Direction

4

Electrical Output Form

Table SJ500-1

Hall Output

HV1:DC5V 0-2.5-5V

HV2:DC5V 0.5-2.5-4.5V

HV3:DC5V 1.0-2.5-4.0V

HV4:DC5V 1.25-2.5-3.75V

Potentiometer Output

P1:Ordinary two directions output

P11a: Ordinary double direction opposite output

P11b: Ordinary double direction same output

5

Potentiometer Type

1K,2K,5K,10K,20K,H-Hall

6

Quantity of Switch

Quantity of Switch Signal 01, 02 and 03. Refer to appendix 4-3 of conventional closed form

7

Common Closed Position

8

Handle Type

Standard Configuration

9

Remark

Line with, special instructions, do not need not.
